Manitowoc 14000 Service And Maintenance Manual

Reference Only
HOISTS 14000 SERVICE MANUAL
5-6
Published 09-10-14, Control # 065-24
FIGURE 5-5
3 to 4 Wraps of Wire Rope
Remaining on Drum
View B
From Right Side of Crane
Drum 1 — Front Drum Shown
Drum 2 — Rear Drum Similar
Item Description Item Description
1 Lever 7 LED (Light Emitting Diode)
2 Rollers 8 Limit Switch Lever with Roller
3 Cap Screw 9 Setscrew
4 Drum 10 Limit Switch Shaft
5 Actuator 11 Return Spring
6 Limit Switch 12 Eyebolt
1
2
3
11
2
1
1-5/32 in (29,5 mm)
at Assembly
6
5
12
8
10
9
6
7
Rotate Head so Lever
is Here with Relation
to LED (7)
View A
View C
3
4
195918
A17917
A907
14CSM4-2
M100004
Limit Switch Wiring
Receptacle
Switch
Terminals
Function
1 (green) 22
B14
Max Angle
2 (black) A
13
LED
3 (white) 21 24 VDC Supply
Current Production
Past Production
