14000 SERVICE MANUAL POWER TRAIN
7
Item Description
1 Air Cleaner Assembly
1a
Evacuator
™ Valve
1b Service Cover
1c Latch
1d Primary Filter
1e Safety Filter
1f Housing
2 Air Inlet Cap
3Clamp
4 Rubber Reducer
5 Rubber Elbow
6Engine Intake
7 Mounting Bands
8 Service Indicator
8a Service Window
8b Reset Button
2
1a
1b
1c
1d
1e
FIGURE 7-4
Left Side of Upperworks
8
8b
8a
P2366
1f
3
6
3
4
3
7
5
8
A15873
Past Production Tier 3
