14000 SERVICE MANUAL INTRODUCTION
1
Right
Travel
Motor
Left Travel Pump #3
Pump
Drive
Right Travel Pump #1
Forward
Forward
Reverse
Reverse
Charge Pressure for Low
Pressure Accessories
Suction
Manifold
Suction
Manifold
350 psi
(24 bar)
350 psi
(24 bar)
Right
Travel
Brake
Left
Travel
Brake
Left
Travel
Motor
Left Travel
Pressure Sender
Right Travel
Pressure Sender
Shuttle
Valve
Shuttle
Valve
Swivel
Pump
Drive
Reverse
Forward
Reverse
Forward
Sequence
Valve
Sequence
Valve
290 psi
(20 bar)
290 psi
(20 bar)
HS-10
Diverter
Valve
Travel
Brake
Travel 2-
Speed
HS-16
HS-15
To D ru m 3
Brake
To D ru m 3
Motor
To Other
Items
14CSM1-109
B
A
B
A
A
B
BA
FIGURE 1-19
