INTRODUCTION 14000 SERVICE MANUAL
1-62
Published 09-10-14, Control # 065-24
FIGURE 1-35
Suction
Manifold
Drum 1 Pump #2
Raise
Lower
350 psi
(24 bar)
.060
Equalizing
Line
Accessory
System
Pressure
Sender
X
Upper Accessory Valve
To Lower Accessory Valve
Boom Hinge Pin Engaged
600 psi (41 bar)
Suction
Manifold
Drum 1 Pump #2
Raise
Lower
350 psi
(24 bar)
.060
Equalizing
Line
Accessory
System
Pressure
Sender
X
Upper Accessory Valve
To Lower Accessory Valve
Boom Hinge Pin Disengaged
600 psi (41 bar)
Pressure
Sender
Pressure
Sender
14CSM1-124
B
A
B
A
14CSM1-125
HS-27
HS-27
