ELECTRIC SYSTEM 14000 SERVICE MANUAL
3-12
Published 09-05-14, Control # 226-02
34-C Ground
Travel 2-Speed Ground
34-D DO-12
Travel 2-Speed 0 Volts Off; 24 Volts On CAN21-2-8
34-E Ground
Swing Brake Release Ground
34-F DO-13
Swing Brake Release 0 Volts Off; 24 Volts On CAN21-2-16
34-G Ground
Drum 3 Converter Ground
34-H DO-14
Drum 3 Converter 0 Volts Off; 24 Volts On CAN21-2-32
34-J Ground
Drum 3 Pawl - In Ground
34-K Ground
Back Hitch Pins Disengage Ground
34-L Ground
Drum 4 Pawl - In Ground
34-M DO-17
Drum 4 Pawl - In 0 Volts Off; 24 Volts On CAN21-3-1
34-N Ground
Boom Hinge Pin Puller Ground
34-P DO-16
Boom Hinge Pin Puller 0 Volts Off; 24 Volts On CAN21-2-128
34-R DO-15
Drum 3 Pawl - In 0 Volts Off; 24 Volts On CAN21-2-64
34-S DO-18
Back Hitch Pins Disengage 0 Volts Off; 24 Volts On CAN21-3-2
34-T Ground
Cab Tilt Down Ground
34-U DO-19
Cab Tilt Down 0 Volts Off; 24 Volts On CAN21-3-4
34-V Ground
Cab Tilt Up Ground
34-W DO-20
Cab Tilt Up 0 Volts Off; 24 Volts On CAN21-3-8
34-X Ground
Drum 3 Pawl - Out Ground
34-Z DO-21
Drum 3 Pawl - Out 0 Volts Off; 24 Volts On CAN21-3-16
34-a Ground
Drum 4 Pawl - Out Ground
34-b DO-22
Drum 4 Pawl - Out 0 Volts Off; 24 Volts On CAN21-3-32
34-c Ground
Drum 3 Brake Release Ground
34-d DO-23
Drum 3 Brake Release 0 Volts Off; 24 Volts On CAN21-3-64
34-e Ground
Drum 3 Motor Control Ground
34-f DO-24
Drum 3 Motor Control See Table 3-2 for Values CAN21-3-128
34-g Ground
Jumper to Node Select 2 Ground
34-j NS-2
Node Select 2 Jumper to Ground 0 Volts (With Jumper)
34-n 24 Volts
Drum 3 Speed Sensor 24 Volts Nominal
34-p EC3A
Drum 3 Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN38-3
2
34-r Ground
Drum 3 Speed Sensor Ground
34-s EC3B
Drum 3 Speed Sensor
1.2 or 3.2 Volts Not Moving;
2.2 Volts Moving
CAN38-3
2
J6/W36 Receptacle - Drum 1 and 2 Free Fall (optional items)
36-A Ground
Drum 1 Proportional Valve A Ground
36-B DO-7
Drum 1 Proportional Valve A 0 Volts Off; 24 Volts On CAN21-1-64
36-C Ground
Drum 2 Proportional Valve B Ground
36-D DO-8
Drum 2 Proportional Valve B 0 Volts Off; 24 Volts On CAN21-1-128
36-E Ground
Drum 1 and 2 Free Fall Enable
Rigging Winch Enable
Ground
36-F DO-9
Drum 1 and 2 Free Fall Enable
Rigging Winch Enable
0 Volts Off; 24 Volts On CAN21-2-1
36-G Ground
Drum 2 Free Fall Enable/Jumper to NS-2 Ground
36-L NS-2
Node Select 2 Jumper to Ground 0 Volts (With Jumper)
36-P DI-7
Remote Control - Back Hitch Pins 0 Volts Off; 24 Volts On CAN38-1-64
