M100004
FIGURE 5-5
3 to 4 Wraps of Wire Rope
Remaining on Drum
View B
From Right Side of Crane
Drum 1 — Front Drum Shown
Drum 2 — Rear Drum Similar
Item Description Item Description
1 Lever 7 Limit Switch
2 Rollers 8 Limit Switch Lever with Roller
3 Cap Screw 9 Setscrew
4 Drum 10 Limit Switch Shaft
5 Actuator 11 Return Spring
6 Limit Switch Cover 12 Eyebolt
1
2
3
11
2
1
1-5/32 in (30 mm) at
Assembly
6
5
12
8
10
9
6
Rotate Head so Lever
is Here with Relation
to Cover (6)
View A
View C
3
4
195918
A17917
A907
Limit Switch Wiring
Receptacle
Switch
Terminals
Function
1 (green) 22
B14
Max Angle
2 (black) A
13
System Ground
3 (white) 21 24 VDC Supply
7
To Next Page
