Left Side Components
Item Description Item Description
1 Right Travel Pump #1 (not shown) 17 Boom Hoist Pressure Sender
2 Drum 1 (Front Drum) Pump #2 18 Node 4 Controller
3 Drum 3/Left Travel Pump #3 19 Swing Gearbox
4 Drum 4 (Boom Hoist) Pump #4 20 Swing Brake
5 Drum 2 (Rear Drum) Pump #5 21 Swing Motor
6 Swing Pump #6 22 Swing Left Pressure Sender
7 Engine Air Cleaner 23 Swing Right Pressure Sender
8 Air Inlet Cap 24 Drum 1(Rear Drum) Motor
9 Return Manifold (hydraulic fluid) 25 Drum 1 Pressure Sender - High
10 Air Cleaner Service Indicator 26 Drum 1 Pressure Sender - Low
11 Suction Manifold (hydraulic fluid) 27 Drum 1 (Rear Drum) Brake Solenoid
12 Travel Right Pressure Sender 28 Drum 2 (Rear Drum) Motor
13 Travel Left Pressure Sender 29 Drum 2 (Rear Drum) Brake Solenoid
14 Suction Vacuum Switch 30 Drum 2 Pressure Sender
15 Boom Hoist Motor 31 Node 3 Controller
16 Boom Hoist Brake Solenoid 32 Remote Controls
