Manitowoc 14000 - Page 77

Reference Only
Manitowoc Published 09-05-14, Control # 226-02 1-65
14000 SERVICE MANUAL INTRODUCTION
1
FIGURE 1-35
Suction
Manifold
Drum 1 Pump #2
Raise
Lower
350 psi
(24 bar)
.060
Equalizing
Line
Accessory
System
Pressure
Sender
X
Upper Accessory Valve
Pressure
Sender
Swivel
Pressure
Sender
Left
Crawler
Pin
Lower Accessory Valve
Left Carbody Jacks
Right
Crawler
Pin
Right Carbody Jacks
3,100 psi
(215 bar)
14CSM1-129
B
A
