HYDRAULIC SYSTEM 14000 SERVICE MANUAL
2-6
Published 09-05-14, Control # 226-02
8. Reinstall fill cap and securely tighten.
9. Start engine and allow hydraulic system to return to
normal operating pressure and temperature. Check filter
fill cap and return line cap for leaks. Tighten as required.
10. Stop engine, check hydraulic tank level, and refill as
required.
M100619
Cover
Body
Head
Outlet to Tank
Return Filter
O-Ring
FIGURE 2-6
Element
O-Rings
O-Ring
Inlet
