Manitowoc 999 Service And Maintenance Manual

Reference Only
ELECTRIC SYSTEM 999 SERVICE/MAINTENANCE MANUAL
3-24
Published 05-16-17, Control # 233-03
I/O 3 J9-52 (AI) A-32 Spare
I/O 3 J9-54 (AI) A-33 Spare
I/O 3 J10-01 (DI) E-03 Spare Encoder CH 5A
Above 7.5 Volts or 0 Volts Not Moving;
3.5 Volts Moving
I/O 3 J10-02 (DI) E-04 Spare Encoder CH 5B
Above 7.5 Volts or 0 Volts Not Moving;
3.5 Volts Moving
I/O 3 J10-03 (DI) E-05 Spare
I/O 3 J10-04 (DI) E-06 Spare
I/O 3 J10-06 (AO) E-29 82MC Boom Hoist Drum Motor Control
0 Volts to 1/3 Handle Motion
0.96 to 2.19 Volts 1/3 Full Handle Motion
I/O 3 J10-07 (DI) B-29 Spare
I/O 3 J10-08 (DI) B-30 89D5 Counterweight Pins Retract Switch 12 Volts Nominal
I/O 3 J10-09 (DI) B-31 89E5 Boom Hinge Pins Extend Switch 12 Volts Nominal
I/O 3 J10-10 (DI) B-32 89F5 Boom Hinge Pins Retract Switch 12 Volts Nominal
I/O 3 J10-11 (DI) B-33 89K Display Scroll Down Switch 12 Volts Nominal
I/O 3 J10-12 (DI) B-34 89Q3 Seat Switch 12 Volts Nominal
I/O 3 J10-13 (DI) B-35 89L1 High Speed Travel Switch 12 Volts Nominal
I/O 3 J10-14 (DI) B-36 89G5 Accessory Pressure Switch 12 Volts Nominal
I/O 3 J10-15 (DI) D-08 89Y3 Front Drum Park Brake Switch 12 Volts Nominal
I/O 3 J10-16 (DI) D-09 89X3 Rear Drum Park Brake Switch 12 Volts Nominal
I/O 3 J10-17 (DI) D-10 89T4 Boom Drum Park Brake Switch 12 Volts Nominal
I/O 3 J10-18 (DI) D-11 89B4 Travel Park Brake Switch 12 Volts Nominal
I/O 3 J10-19 (DI) D-12 89S4 Auxiliary Drum Park Brake Switch 12 Volts Nominal
I/O 3 J10-20 (DI) D-13 89R1 Auxiliary Drum Minimum Bail Limit Switch 12 Volts Nominal
I/O 3 J10-23 (DO) D-26 56A Counterweight Pins Retract Solenoid 12 Volts Nominal
I/O 3 J10-23-24 (DO) D-27 80N Front Drum Rotation Indicator 12 Volts Nominal
I/O 3 J10-25-26 (DO) D-28 81N Rear Drum Rotation Indicator 12 Volts Nominal
I/O 3 J10-27-28 (DO) D-29 82N Boom Drum Rotation Indicator 12 Volts Nominal
I/O 3 J10-29-30 (DO) D-30 86N Auxiliary Drum Rotation Indicator 12 Volts Nominal
I/O 3 J10-31-32 (DO) D-31 84R High Speed Travel Solenoid 12 Volts Nominal
I/O 3 J10-33-34 (DO) D-32 80R Front Drum Pawl Enable Solenoid 12 Volts Nominal
I/O 3 J10-35-36 (DO) D-33 80RA Front Drum Pawl Disable Solenoid 12 Volts Nominal
I/O 3 J10-37-38 (DO) D-34 81R Rear Drum Pawl Enable Solenoid 12 Volts Nominal
I/O 3 J10-39-40 (DO) D-35 81RA Rear Drum Pawl Disable Solenoid 12 Volts Nominal
I/O 3 J10-41 (AO) C-23 84A Left Track Pump Control (Servo Driver 5)
0 to 2.8 ± 10% (110 mA) Volts Reverse;
0 to -2. 8 ± 10% (-110 mA) Volts Forward
I/O 3 J10-42 (AO) C-24 85A Swing Pump Control (Servo Driver 6)
0 to 2.8 ± 10% (110 mA) Volts Right;
0 to -2. 8 ± 10% (-110 mA) Volts Left
I/O 4 J12-01 (DI) E-25 Spare
I/O 4 J12-02 (DI) E-26 Spare
I/O 4 J12-03 (DI) E-27 Spare
I/O 4 J12-04 (DI) E-28 Spare
I/O 4 J12-06 (AO) E-30 86MC Auxiliary Drum Motor Control
0 Volts to 1/3 Handle Motion
0.96 to 2.19 Volts 1/3 Full Handle Motion
I/O 4 J12-07 (DI) D-14 Spare
I/O 4 J12-08 (DI) D-15 85EA Swing Park Brake Switch 12 Volts Nominal
Board
(Signal Type)
Pin Wire Description
Test Voltage
(DC unless otherwise specified)
