ELECTRIC SYSTEM 999 SERVICE/MAINTENANCE MANUAL
3-2
Published 05-16-17, Control # 233-03
CIRCUIT BREAKER AND FUSE ID
Refer to Figure 3-1 for the location and identification of the
fuses and circuit breakers on this crane.
FIGURE 3-1
Item Description See
1 Fuse Junction Box in Operator’s Cab page 3-3
2 Cold Weather Circuit Breaker Load Center page 3-4
3 Battery and Alternator Fuses page 3-4
4 Engine Node page 3-5
5 CraneStar TCU Fuses page 3-6
6 Exhaust Aftertreatment Junction Box page 3-6
1
3
4 65
2
