999 SERVICE/MAINTENANCE MANUAL BOOM
4
FIGURE 4-1
1
5
Centerline of
Boom
Horizontal
A
See Table 4-1
Item Description
1 Boom Butt
2 Adjusting Rod
5 Limit Switch
2a,
2b,
or
2c
See Table 4-1
