POWER TRAIN 999 SERVICE/MAINTENANCE MANUAL
7-12
Published 05-16-17, Control # 233-03
FIGURE 7-10
Item Description
1 Level Sight Glass
2 Fill Cap
3 Coolant Level Sensor
4 Air Bleed Valve
5 Charge Air Cooler
6 Radiator Drain Valve with Hose
7 Hydraulic Oil Cooler
8 Radiator
81009399_a
2
1
4
5
6
8
1
2
3
7
Shown with Engine Enclosure Removed for Clarity
(see Figure 7-8
for access points)
