6 Installation
Operating and Installation Instructions UL 36
Fastening the base frame
1.
Stacking kit with 6" and 12" foot height
1.a
Use an open-end wrench with a width across flats of 13 mm
together with the four enclosed hex screws, the Schnorr locking
washers, and the flat washers to attach the base frame.
1.b
In addition, fasten the two long hex screws on the left side of
the base frame.
The specific fasteners that are included will depend on the
specific stacking kit model being used. Use self-tapping screws
or metric bolts as appropriate for the model you are using.
2.
Stacking kit with casters
2.a
Use an open-end wrench with a width across flats of 13 mm
together with the four enclosed hex screws and the Schnorr
locking washers to attach the base frame with casters (casters
with brake in the front).
