6 Installation
Operating and Installation Instructions UL 46
4.a CE:
Mount the trap elbow.
4.b UL:
Slip the trap elbow onto the drain box’s drain pipe.
Use a hose clamp to secure the trap elbow.
5. Bend the part of the door contact switch holding plate that is in
front of the perforation 90° downwards.
6.
Put the unit back upright and place lumber or other suitable
materials with a height of at least 60 mm underneath it.
Make sure to place the lumber next to the covers for the pumps
and the drain box.
