SETUP AND INSTALLATION MLC90A-1/MLC100-1 OPERATOR MANUAL
4-14
Published 12-10-19, Control # 258-05
Item Description
1 Counterweight Links (both sides)
2 Safety Pin (qty 2)
3 Collar (qty 2)
4Pin (qty 2)
5Gantry
6 Gantry Cylinder
7 Backhitch Links
8 Front Drum Load Line (stored)
View A
View B
View C
View E
View D
Figure 4-8
457 mm (18 in)
