SETUP AND INSTALLATION MLC90A-1/MLC100-1 OPERATOR MANUAL
4-26
Published 12-10-19, Control # 258-05
Item Description
1 Boom Butt at 81°
2 Boom Stop Spring Compressed (qty 2)
2A Boom Stop Outer Tube (Qty 2)
2B Boom Stop Inner Tube (Qty 2)
3 Hold-Back Pin with Hair-Pin Cotter (Qty 2)
4 Crane Counterweight
5 Adjustable Handling Link (Qty 2)
S Storage Holes
W Working Holes
Figure 4-16
View A
View B
View C
50 mm (2 in)
