Manitowoc MLC100-1 - Page 138

SETUP AND INSTALLATION MLC90A-1/MLC100-1 OPERATOR MANUAL
4-28
Published 12-10-19, Control # 258-05
Figure 4-17
View A
Item Description
1 Crane Counterweight
2 Handling Pendants (Qty 4)
3 Handling Links (Qty 2)
4 Pendant Pins with Safety Pins (Qty 4)
5 Adjustable Handling Link (Qty 2)
6 Front Handling Link (Qty 2)
View B
View C
NOTE Larger radius corresponds to
longer distance between holes.
1180 mm
(46.5 in)
2°
