SAFETY INFORMATION MLC90A-1/MLC100-1 OPERATOR MANUAL
2-4
Published 12-10-19, Control # 258-05
Figure 2-1. Crane Access Points
Item Description
Material
1 Steps (both crawlers) Non-skid grating
1A Steps (stowed) Non-skid grating
1B Steps (working) Non-skid grating
2 Platform (both sides) Non-skid grating
3 Carbody Counterweight Non-skid paint
4 Steps Non-skid grating
5 Handrails
6 Enclosure Platforms Non-skid strips
7 Crane Counterweight (not shown) Non-skid paint
8 Ladder Grated rungs
9 Platform Non-skid strips
