MLC90A-1/MLC100-1 OPERATOR MANUAL OPERATING CONTROLS AND PROCEDURES
3
1
3
Energize Lights, Console
Engine Run Light, Position
Engine Start Light, Work (and camera)
Engine Stop Lighter
Fan Off
Gantry On
Heater Park Off
Horn Park On
Table 3-2. Symbol Identification — Control Consoles
M100154
M100165
M100159
M100291
M100160
M100166
M100161
M100167
M100142a
M100170
M102435
M100171
M102084
M100164
M100172
