OPERATING CONTROLS AND PROCEDURES MLC90A-1/MLC100-1 OPERATOR MANUAL
3-10
Published 12-10-19, Control # 258-05
21A Rear View Mirror (optional left side) Adjustable to provide a view to the rear of the crane.
21B Drum Mirror Adjustable to provide a view of the drums.
21C Rear View Mirror (optional right side) Adjustable to provide a view to the rear of the crane.
22 Left Console See page 3-12
for more information.
23 Windshield Washer Fluid Tank
Inside the left enclosure. Fill with a quality brand of non-freezing
windshield washer fluid.
24 HVAC Unit
The main components for heating and cooling the operator cab are
located here.
25 HVAC Filter Element
Remove the cover and replace the filter element every six months, or
sooner in extremely dusty climates. Reinstall the cover.
26 Boom Angle Indicator
See page 3-25
for more information.
27
Engine Foot Throttle and Optional Free
Fall Brake Pedals
See page 3-23
for more information
