National Crane Published 12-21-2011 CTRL #050-09 5-3
5
1300A OPERATOR’S MANUAL LUBRICATION PROCEDURE AND CHARTS
LUBRICATION POINTS
A regular frequency of lubrication must be established based
on component operating time. The most efficient method of
keeping track of lube requirements is to maintain a job log of
crane usage.
All oil levels are to be checked with the crane parked on a
level surface in transport position, an
d while the oil is cold,
unless otherwise specified. On plug type check points, the oil
levels are to be at the bottom edge of the fill port.
Over lubrication of non-sealed fittings will not harm the
fittings or components, but under lubrication shortens
lifetime.
Worn grease fittings that do not hold a grease gun, or those
that have a stuck check ball, must be replaced.
When wear pads or rotation bearings are lubricated, cycle
the components and lubricate again to ensure complete
lubrication of the entire wear area.
CAUTION
Lubrication intervals (page 5-3) are to be used only as a
guide. Actual intervals should be formulated by the
operator to correspond accordingly to conditions such as
continuous duty cycles and/or hazardous environments.
Symbol Description Manitowoc Lube Specification
EP-MPG Extreme Pressure Multipurpose Grease - Lithium Soap Base, NLGI Grade 2. A6-829-003477
EP-3MG Extreme Pressure Moly Grease A6-829-015304
GL-5 Extended Service Interval Gear Lubricant - SAE Grade 80W-90 A6-829-012964
AFC - 50/50 50/50 Blended Fully Formulated Antifreeze/Coolant, SAE J1941, ASTM D6210 A6-829-101130
HYDO Hydraulic Oil - Must meet ISO 4406 cleanliness level 17/14 A6-829-006444
EO-15W/40 Engine Oil - SAE 15W-40, API Service Classification CI-4 or better A6-829-003483
EP-OGL Open Gear Lubricant, CEPLATTYN 300 Spray, NLGI Grade 1-2 A6-829-102971
AGMA EP-4 Extreme Pressure Gear Lubricant. A6-829-100213
WRL Wire Rope Lubricant A6-829-015236
LTG Low Temperature Grease, NLGI Grade 1 A6-829-225828
