U0240 SELF-CONTAINED WATER-COOLED
NOTE: These characteristics may vary depending on
operating conditions.
Cycle Times
Freeze Time + Harvest Time = Cycle Time
Times in minutes
24 Hour Ice Production
Based on average ice slab weight of 2.44 - 2.75 lb (1107 – 1247 g).
Regular cube derate is 7%
Water regulating valve set to maintain 235 PSIG discharge pressure
Condenser water usage = 149 gallons per 100 lbs of ice at 90°F/70°F
Operating Pressures
Suction pressure drops gradually throughout the freeze cycle.
Air Temp.
Around Ice
Machine °F/°C
Freeze Time
Harvest
Time
Water Temperature °F/°C
50/10 70/21 90/32
70/21
16.1-18.3 17.0-19.3 18.0-20.5
1.0-2.5
80/27
16.5-18.8 17.5-19.9 18.6-21.1
90/32
17.0-19.3 18.0-20.5 19.2-21.8
100/38
17.5-19.9 18.6-21.1 19.9-22.5
110/43
18.0-20.5 19.2-21.8 20.5-23.3
Air Temp. Around
Ice
Machine °F/°C
Water Temperature °F/°C
50/10 70/21 90/32
70/21
200 190 180
80/27
195 185 175
90/32
190 180 170
100/38
185 175 165
110/43
180 170 160
Air Temp.
Around Ice
Machine
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
50/10 230-240 65-30 130-150 80-110
70/21 230-240 70-32 135-160 90-120
80/27 230-240 70-34 135-160 90-120
90/32 230-240 70-36 135-165 90-120
100/38 230-245 75-35 135-170 90-120
110/43 230-250 80-38 140-175 95-125
