Part Number STH042 3/14 45
Bin Removal
1. Disconnect power.
1. Remove all ice from bin.
2. Loosen screws and slide clips to release.
3. Disconnect clamp and remove bin drain.
4. Disconnect touch pad communication cable.
5. Slide bin forward to remove.
NOTE: When reinstalling the bin, insure the bin seal is
in place and is not pinched/folded as it mates to the
cabinet. A water tight seal is required to prevent future
condensation or water leakage from entering the ice
machine base.
LOOSEN SCREWS AND SLIDE CLIPS
DISCONNECT CLAMP AND REMOVE BIN DRAIN
DISCONNECT COMMUNICATION CABLE
