36 Part Number STH042 3/14
REMOVE PARTS FOR CLEANING
A. Remove the Harvest Float Switch and Ice
Thickness Float Switch
• Pull forward on the bottom of the bracket until clear
of the tab, then slide bracket upward to remove the
bracket and float as an assembly. At this point, the
float switch’s can easily be cleaned. If complete
removal is desired follow the wires to the bulkhead
grommet (exit point) in the back wall. Pull the wire
connector through the bulkhead grommet, then
disconnect the wire leads from the connector.
NOTE: The wire from the top grommet goes to the ice
thickness float switch (front switch). The wire from the
bottom grommet goes to the Harvest float switch (side
switch).
