Manitowoc NEO - Energized Parts Chart; Ice Making Sequence Component States

54 Part Number STH042 3/14
ENERGIZED PARTS CHART Self-Contained Ice Machines
ICE MAKING SEQUENCE OF OPERATION
Water Pump Harvest
Valve
Water Inlet
Valve
Dump
Valve
Compressor
&
Condenser Fan
Motor*
Harvest
Float Switch
Ice Thickness
Float Switch
Length of
Time
Initial Start-up
1. Water purge
OFF ON OFF ON OFF CLOSED CLOSED 20 seconds
2. Refrigeration
System
Start-up
OFF ON OFF OFF ON CLOSED CLOSED 5 seconds
Freeze Sequence
3. Pre chill
OFF OFF ON OFF ON OPEN CLOSED
120
Seconds
initial cycle
Thereafter
60 seconds
