50 Part Number 8001119 10/19

Disassembly

SV1211

INNER

TUBE

TAB

KEYWAY

INNER

TUBE

• Twist both of the inner tube ends until the tabs line

up with the keyways.

• Pull the inner tube ends outward.

Q210/Q270 Water Distribution Tube Disassembly
