Part Number 8001119 10/19 53
G. Remove the Water Trough
• Apply downward pressure on the siphon tube and
remove from the bottom of the water trough.
• Remove the upper thumbscrew.
• While supporting the water trough remove the two
thumbscrews from beneath the water trough.
• Remove the water trough from the bin area.
REMOVE THE ICE DAMPER.
SV1689-1
UPPER
THUMBSCREW
SV1689-2
LOWER
THUMBSCREWS
REMOVE
SIPHON
TUBE
To Next Page
