T2 TEMPERATURE/RESISTANCE CHART
Important
If the ohmmeter reads “OL,” check the scale setting on
the meter before assuming the thermistor is bad.
Temperature Resistance Temperature Resistance

K Ohms


K Ohms

-40 225.1 36 6.623
-39 212.8 37 6.387
-38 200.6 38 6.162
-37 189.3 39 5.945
-36 178.7 40 5.738
-35 168.8 41 5.538
-34 159.4 42 5.347
-33 150.6 43 5.163
-32 142.4 44 4.987
-31 134.7 45 4.817
-30 127.5 46 4.655
-29 120.6 47 4.498
-28 114.2 48 4.348
-27 108.2 49 4.203
-26 102.5 50 4.064
-25 97.20 51 3.931
-24 92.17 52 3.803
-23 87.44 53 3.680
-22 82.97 54 3.561
-21 78.77 55 3.446
-20 74.80 56 3.336
-19 71.05 57 3.230
-18 67.52 58 3.127
