Precision Video Scaling II
™
• 10-bit fully programmable horizontal and vertical scaler
• Upscales to 1080p and downscales to VGA format
• Automatic Chroma Upsampling Error detection and correction
• Aspect ratio control for displaying 4:3 inputs on 16:9 displays
— Includes non-linear stretch (panorama) mode
• Deinterlaces using field scaling techniques
Picture Controls
• Brightness
• Contrast
• Saturation
• Sharpness (vertical and horizontal)
• Sub-pixel Y/C delay
• Output black level
• Dynamic Range Expansion for full range output
Host Interface
• Two wire serial bus interface (I
2
C compatible)
Power
• 1.8V core and 3.3V I/O
Package
• 100-pin PQFP
Availability
• Currently available
Ordering Information
• ABT1010PQ100A-7
ANCHOR BAY TECHNOLOGIES • 300 ORCHARD CITY DRIVE • SUITE 131 • CAMPBELL, CA 95008
PATENTS APPLIED FOR & PENDING
ABT1010PB_031607
www.anchorbaytech.com
ABT1010
