Marantz AV8003 - Page 157

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
DSP CC52 ns
p
00MDK96102300 CER. CAP.
1000PF 50V KC
CCUS1H102KC
DSP CC53 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CC54 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CC56 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP
CC57
00MDK96104300
CER CAP
UF V K
DSP
CC57
ns
p
00MDK96104300
CER
.
CAP
.
0.1
UF
50
V
K
CCUS1H104KC
DSP CC58 ns
p
00MDK96102300 CER. CAP.
1000PF 50V KC
CCUS1H102KC
DSP CC59 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CC60 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CC61 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CC62 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CC63 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
DSP CC64 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CC65 ns
p
00MOA22605020 ELECT CAP.
22UF 50V
CCEA1HH220T
DSP
CC66
nsp
00MDK96104300
CER CAP
0 1UF 50V K
CCUS1H104KC
DSP
CC66
nsp
00MDK96104300
CER
.
CAP
.
0
.
1UF
50V
K
CCUS1H104KC
DSP CN15 ns
p
ns
p
CONN.
12P WAFER 2MM PITCH YDW200-12
CJP12GA147ZY
DSP CN16
/
U1B ns
p
ns
p
CONN.
12P WAFER 2MM PITCH YDW200-12
CJP12GA147ZY
DSP CN17 ns
p
ns
p
CONN.
3P STRAIGHT YMW025-03R
CJP03GA01ZY
DSP CN62 ns
p
ns
p
CONN.
5P STRAIGHT 20017WS-05
CJP05GA19ZY
DSP CN63 ns
p
ns
p
CONN.
17P WAFER FFC FCZ100E-17SSK
CJP17GA117ZY
DSP CN65
/
U1B ns
p
ns
p
CONN.
15P WAFER FFC 12511HS-15
CJP15GA115ZY
DSP CN68 ns
p
ns
p
CONN.
17P WAFER FFC FCZ100E-17SSK
CJP17GA117ZY
DSP CN71 ns
p
ns
p
CONN.
17P WAFER FFC FCZ100E-17SSK
CJP17GA117ZY
DSP CN73 ns
p
ns
p
CONN.
3P STRAIGHT 20017WS-03
CJP03GA19ZY
p
p
DSP CN77 ns
p
ns
p
CONN.
3P STRAIGHT YMW025-03R
CJP03GA01ZY
DSP CN78 ns
p
ns
p
CONN.
17P WAFER FFC 12511HS-17
CJP17GA115ZY
DSP CN80 ns
p
ns
p
CONN.
13P WAFER STRAIGHT 20017WS-13
CJP13GA19ZY
DSP CN81 ns
p
ns
p
CONN.
10022HS
CJP15GA193ZY
DSP CN83 ns
p
ns
p
CONN.
13P WAFER
CJP13GA193ZY
DSP CN90 ns
p
ns
p
CONN.
17P WAFER FFC 12511HS-17
CJP17GA115ZY
DSP CR10 ns
p
90M-OA000540R ELECT CAP.
220UF 16V ESR
CCEA1CKXL221T
DSP CR11 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CR13 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
DSP CR14 ns
p
00MOA10702520 ELECT CAP.
100UF 25V
CCEA1EH101T
DSP CR15 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CR16 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CR17 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
DSP CR18 ns
p
90M-OA000540R ELECT CAP.
220UF 16V ESR
CCEA1CKXL221T
DSP CR19 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
DSP CR20 ns
p
90M-OA000540R ELECT CAP.
220UF 16V ESR
CCEA1CKXL221T
DSP CR21 ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
DSP CR22 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP
CR23
nsp
00MOA10605020
ELECT CAP
10UF 50V
CCEA1HH100T
DSP
CR23
nsp
00MOA10605020
ELECT
CAP
.
10UF
50V
CCEA1HH100T
DSP CR24 ns
p
00MOA22701620 ELECT CAP.
220UF 16V
CCEA1CH221T
DSP CR25 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
DSP CR26 ns
p
00MOA22701620 ELECT CAP.
220UF 16V
CCEA1CH221T
DSP CR27 ns
p
00MDK96102300 CER. CAP.
1000PF 50V KC
CCUS1H102KC
DSP CR28 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CR29 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CR30 ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
DSP CR31 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
D
S
P
C
R
3
2n
sp
00
MDK
96
1
0
4
300
C
ER.
C
AP.
0.1UF 50V K
CCUS1H104KC
S
C3
sp
00 96 0 300
CC
DSP CR34
/
U1B ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CR35
/
U1B ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
DSP CR36
/
U1B ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CR40 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CR41 ns
p
90M-OA000680R ELECT CAP.
KR3-16V472MH-L/C4.0 16V/4700
CCEA1CH472EZ
DSP CR42
/
U1B ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP CR47
/
U1B ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
DSP CR48
/
U1B ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
DSP DC10
/
N1B 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP DC11 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP DC12
/
U1B ns
p
00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP DC13 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP DC14 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP DC15 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP DC16 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
DSP DC17 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
193
