Marantz AV8003 - Page 158

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
DSP DC18 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP DC19 90M-HI200020R 90M-HI200020R L.E.D.
SIR-34ST3F
BVDSIR34ST3F
DSP DC20 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP DC21 00MHZ21303210 00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP
DC22
00MHZ21303210
00MHZ21303210
DIODE
SS
DSP
DC22
00MHZ21303210
00MHZ21303210
DIODE
1
SS
355
CVD1SS355T
DSP DC23
/
U1B ns
p
00MHZ21303210 DIODE
1SS355
CVD1SS355T
DSP ET01 ns
p
ns
p
TERMINAL
EARTH PLATE
CNE75
DSP ET02 ns
p
ns
p
TERMINAL
EARTH PLATE
CNE75
DSP ET03 ns
p
ns
p
BRACKET
BRACKET SHIELD
CMD1A512
DSP ET04 ns
p
ns
p
BUFFER
STOPPER IR SENSOR
CHG1A262
DSP IC12 90M-HW100710R 90M-HW100710R PHOTO UNIT
PC-17L1CB
HVIPC17L1CB
DSP IC13 00MHC008205K0 00MHC008205K0 IC
TC74VHC08FT
CVITC74VHC08FT
DSP IC14 90M-HW100690R 90M-HW100690R PHOTO UNIT
RPM674CBR-S
CRVRPM6936
DSP
IC15
/N1B
90M-HC110110R
90M-HC110110R
IC
AT24C32CN-SH-T
CVIAT24C32CNSHT
DSP
IC15
/N1B
90M-HC110110R
90M-HC110110R
IC
AT24C32CN-SH-T
CVIAT24C32CNSHT
DSP IC15
/
U1B ns
p
90M-HC110120R IC
AT24C64CN-SH-T
CVIAT24C64CNSHT
DSP IC16 90M-HC108430R 90M-HC108430R IC
TC74HC7007AFEL
HVITC74HCT7007F
DSP IC17 943243001610M 943243001610M U-PRO
M3087BFKBGP MAIN AV8003
CVIM3087BFKBGP
DSP 00M46CW499A00 00M46CW499A00 SOFTWARE
FIRMWARE FOR IC17
DSP IC18 943235001630S 943235001630S IC
S-80145ANMC-JC6-T2 RESET
CVIS80145ANMCJC6T2
DSP IC19 00MHC705205Y0 00MHC705205Y0 IC
TC74HC4052AFT
CVITC74HC4052AFT
DSP IC20 943234001580S 943234001580S IC
CD74HCT4094M96G4
CVICD74HCT4094M96G4
DSP IC21 943234001580S 943234001580S IC
CD74HCT4094M96G4
CVICD74HCT4094M96G4
DSP IC22 00MHC700400Z0 00MHC700400Z0 IC
TC74HCU04AFN
HVITC74HCU04AFN
DSP IC23 00MHC011905K0 00MHC011905K0 IC
TC74VHC153FT
CVITC74VHC153FT
DSP IC24 90M-HC700630R 90M-HC700630R IC
TC74VHCT04AFN
CVITC74VHCT04AFN
DSP IC25 00MHC10172090 00MHC10172090 IC
NJM2115MD OP AMP
HVINJM2115MDTE1
DSP IC26 00MHC10172090 00MHC10172090 IC
NJM2115MD OP AMP
HVINJM2115MDTE1
DSP IC27 00MHC10015880 00MHC10015880 IC
CS5361-KS A/D CONVERTER
HVICS5361-KS
DSP IC28 00MHC008205K0 00MHC008205K0 IC
TC74VHC08FT
CVITC74VHC08FT
DSP IC29 00MHC10418030 00MHC10418030 IC
LC89057W-VF4A-E
CVILC89057WVF4AE
DSP IC31 00MHC009105K0 00MHC009105K0 IC
TC7WH157FU
HVITC7WH157FU
DSP IC32 90M-HC109290R 90M-HC109290R IC
TC74VHC157FT
HVITC74VHC157FT
DSP IC33 ns
p
ns
p
IC
TMS320DA788B DSP
CVITMS320DA788B
DSP IC34 943248001590M 943248001590M U-PRO
ES29LV320ET70TG DSP AV8003
CVIES29LV320ET70TG
DSP 00M36CW499C00 00M36CW499C00 SOFTWARE
DSP CORD FOR IC34
DSP IC35 90M-HC109920R 90M-HC109920R IC
M12L64164A7T
HVIM12L64164A7T
DSP IC36 00MHC008205K0 00MHC008205K0 IC
TC74VHC08FT
CVITC74VHC08FT
DSP IC37 943234001580S 943234001580S IC
CD74HCT4094M96G4
CVICD74HCT4094M96G4
DSP IC39
/
U1B ns
p
90M-HY200050R F.E.T.
UPA672T
CVTUPA672T
DSP IC40
/
U1B ns
p
90M-HY200050R F.E.T.
UPA672T
CVTUPA672T
DSP IC41 90M-HC109790R 90M-HC109790R IC
CS4382A-CQ
CVICS4382A-CQ
DSP
IC42
00MHC10114530
00MHC10114530
IC
S 80810CNNB
CVIS 80810CNNB
DSP
IC42
00MHC10114530
00MHC10114530
IC
S
-
80810CNNB
CVIS
-
80810CNNB
DSP IC43 00MHC10114530 00MHC10114530 IC
S-80810CNNB
CVIS-80810CNNB
DSP IC44 00MHC10102090 00MHC10102090 IC
NJM2068MD-TE1
HVINJM2068MDTE1
DSP IC45 00MHC10102090 00MHC10102090 IC
NJM2068MD-TE1
HVINJM2068MDTE1
DSP IC46 00MHC10102090 00MHC10102090 IC
NJM2068MD-TE1
HVINJM2068MDTE1
DSP IC47 00MHC10102090 00MHC10102090 IC
NJM2068MD-TE1
HVINJM2068MDTE1
DSP IC48 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
DSP IC49 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
DSP IC50 90M-HC900090R 90M-HC900090R IC
KAI7812AF-RTF
HVIKIA7812AF
D
S
PI
C5
1
90
M-H
C900
17
0
R
90
M-H
C900
17
0
RI
C
KIA1117S00-RTK/P
CVIKIA1117S00
S
C5
90 C900 0
90 C900 0
C
DSP IC52 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
DSP IC53
/
U1B ns
p
90M-HC301000R IC
KIA278R00FP
CVIKIA278R00FP
DSP IC58 90M-HC108430R 90M-HC108430R IC
TC74HC7007AFEL
HVITC74HCT7007F
DSP IC59 00MHC705205Y0 00MHC705205Y0 IC
TC74HC4052AFT
CVITC74HC4052AFT
DSP IC60 00MHC705205Y0 00MHC705205Y0 IC
TC74HC4052AFT
CVITC74HC4052AFT
DSP IC61
/
U1B ns
p
90M-HC301000R IC
KIA278R00FP
CVIKIA278R00FP
DSP IC62 90M-HY200050R 90M-HY200050R F.E.T.
UPA672T
CVTUPA672T
DSP IC63 90M-HC108430R 90M-HC108430R IC
TC74HC7007AFEL
HVITC74HCT7007F
DSP JK11 90M-YT005430R 90M-YT005430R TERMINAL
OPT/CINCH RX YKC22-0877V
CJS9U015Z
DSP JK12 90M-YT005430R 90M-YT005430R TERMINAL
OPT/CINCH RX YKC22-0877V
CJS9U015Z
DSP JK13 90M-YT005430R 90M-YT005430R TERMINAL
OPT/CINCH RX YKC22-0877V
CJS9U015Z
DSP JK14 90M-YT005440R 90M-YT005440R TERMINAL
OPT/CINCH TX YKC22-0874V
CJS9U014Z
DSP JK15 90M-YT003120R 90M-YT003120R TERMINAL
CINCH 2P GOLD JE0200598N
CJJ4N036Z
DSP JK16 90M-YT003650R 90M-YT003650R TERMINAL
CINCH 2P GREEN RCA-207AE-11
CJJ4N071Z
DSP JK17 90M-YJ002760R 90M-YJ002760R CONN.
STEREO 2P 3.5MM HSJ1002-016020
HJJ1D002Z
DSP JK18 90M-YJ002760R 90M-YJ002760R CONN.
STEREO 2P 3.5MM HSJ1002-016020
HJJ1D002Z
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
194
