Marantz AV8003 - Page 159

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
DSP JK19 90M-YT004860R 90M-YT004860R TERMINAL
3.5MM JACK STEREO PJ-308-02
CJJ2D008Z
DSP JK20 90M-YT004860R 90M-YT004860R TERMINAL
3.5MM JACK STEREO PJ-308-02
CJJ2D008Z
DSP JP11 ns
p
ns
p
CORD
SN95/PB5 0.6
C3A206
DSP JP12 ns
p
ns
p
CORD
SN95/PB5 0.6
C3A206
DSP
JP13
CORD
SN /PB
DSP
JP13
ns
p
ns
p
CORD
SN
95
/PB
5 0.6
C3A206
DSP JP14 ns
p
ns
p
CORD
SN95/PB5 0.6
C3A206
DSP JP15 ns
p
ns
p
CORD
SN95/PB5 0.6
C3A206
DSP JP16 ns
p
ns
p
CORD
SN95/PB5 0.6
C3A206
DSP LC10 90M-FC900340R 90M-FC900340R FERRITE CORE
HU-1H4516-600JT
CLZ9Z014Z
DSP LC11 90M-FC900340R 90M-FC900340R FERRITE CORE
HU-1H4516-600JT
CLZ9Z014Z
DSP LC12 90M-FC900460R 90M-FC900460R EMI FILTER
CHIP BEAD (EMC FILTER)
CLZ9R007Z
DSP LC13 90M-FC900460R 90M-FC900460R EMI FILTER
CHIP BEAD (EMC FILTER)
CLZ9R007Z
DSP LC14 ns
p
00MNN05000610 CHIP RES.
0 OHM 1/10W J
CRJ10DJ0R0T
DSP
LC15
90M-LU000220R
90M-LU000220R
COIL
10UH CWCI-3225-100
HLQ10E100KRZ
DSP
LC15
90M-LU000220R
90M-LU000220R
COIL
10UH
CWCI-3225-100
HLQ10E100KRZ
DSP LC16 90M-LU000270R 90M-LU000270R CHIP INDUCT
INDUCTOR CHIP NLCV32T-100K-PF
CLQ10E100KRY
DSP QC10 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC11 00MHT30001000 00MHT30001000 TRS.
KTC3199Y
HVTKTC3199YT
DSP QC12 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC13 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC14 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC15 00MHT600121A0 00MHT600121A0 TRS.
KTA1268GR
HVTKTA1268GRT
DSP QC16 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
DSP QC17 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC18 00MHT600121A0 00MHT600121A0 TRS.
KTA1268GR
HVTKTA1268GRT
DSP QC19 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
DSP QC20 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC21 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC22 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC23
/
N1B 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC24
/
N1B 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
DSP QC25 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
DSP QC26 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC27 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
DSP QC28 90M-HT300970R 90M-HT300970R TRS.
KTC2875B
HVTKTC2875B
DSP QC29
/
U1B ns
p
90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
DSP QC30
/
U1B ns
p
90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
DSP QC31
/
U1B ns
p
90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC32 90M-HX600010R 90M-HX600010R CHIP TRS.
KRA102S
HVTKRA102S
DSP QC33
/
U1B ns
p
90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
DSP QC34 90M-HX800010R 90M-HX800010R CHIP TRS.
KRC102S
HVTKRC102S
DSP R100 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP
R101
nsp
00MNN05750610
CHIP RES
75 OHM 1/10W J
CRJ10DJ750T
DSP
R101
nsp
00MNN05750610
CHIP
RES
.
75
OHM
1/10W
J
CRJ10DJ750T
DSP R102 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
DSP R103 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
DSP R104 ns
p
00MNN05330610 CHIP RES.
33 OHM 1/10W J
CRJ10DJ330T
DSP R106 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
DSP R107 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
DSP R108 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
DSP R109 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
DSP R110 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
D
S
P R111 n
sp
00
MNN
05
1
036
1
0
C
HIP RE
S
.
10K OHM 1/10W J
CRJ10DJ103T
S
sp
00 05 036 0
CS
DSP R112 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP R113 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP R114 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP R115 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP R116 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP R117 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
DSP R118 ns
p
00MNN05560610 CHIP RES.
56 OHM 1/10W J
CRJ10DJ560T
DSP R119 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
DSP R120 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
DSP R121 ns
p
00MNN05101610 CHIP RES.
100 OHM 1/10W J
CRJ10DJ101T
DSP R122 ns
p
00MNN05560610 CHIP RES.
56 OHM 1/10W J
CRJ10DJ560T
DSP R123 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP R124 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP R125 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP R126 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
DSP R127 ns
p
00MNN05103610 CHIP RES.
10K OHM 1/10W J
CRJ10DJ103T
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
195
