Marantz AV8003 - Page 176

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
HDMI C910 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C947 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C948 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C949 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI
C950
00MOA47602520
ELECT CAP
UF V
HDMI
C950
ns
p
00MOA47602520
ELECT
CAP
.
47
UF
25
V
CCEA1EH470T
HDMI C951 90M-EA000930R 90M-EA000930R ELECT CAP.
3300UF 16V
CCEA1CH332E
HDMI C952 ns
p
00MOA10605020 ELECT CAP.
10UF 50V
CCEA1HH100T
HDMI C953 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C954 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C955 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C956 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C957 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C958 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI
C959
nsp
00MOA47602520
ELECT CAP
47UF 25V
CCEA1EH470T
HDMI
C959
nsp
00MOA47602520
ELECT
CAP
.
47UF
25V
CCEA1EH470T
HDMI C960 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C961 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C962 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C963 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C964 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C965 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C966 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C967 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C968 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
p
HDMI C969 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C970 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C971 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C972 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C973 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C974 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C975 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C976 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C977 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C978 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C979 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C980 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C981 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C982 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI C983 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C984 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C985 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C986 ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
HDMI
C987
nsp
00MDK96104300
CER CAP
0 1UF 50V K
CCUS1H104KC
HDMI
C987
nsp
00MDK96104300
CER
.
CAP
.
0
.
1UF
50V
K
CCUS1H104KC
HDMI C988 ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
HDMI C989 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C990 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C991 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C992 ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
HDMI C993 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C994 ns
p
00MOA10701620 ELECT CAP.
100UF 16V
CCEA1CH101T
HDMI C995 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI
C996
n
sp
00
MDK
96
1
0
4
300
C
ER.
C
AP.
0.1UF 50V K
CCUS1H104KC
C996
sp
00 96 0 300
CC
HDMI C997 ns
p
00MDK96104300 CER. CAP.
0.1UF 50V K
CCUS1H104KC
HDMI C998 ns
p
00MOA47602520 ELECT CAP.
47UF 25V
CCEA1EH470T
HDMI CN32 ns
p
ns
p
CONN.
11P FPC WAFER
CJP11GA193ZY
HDMI CN37 ns
p
ns
p
CONN.
5P STRAIGHT 20017WS-05
CJP05GA19ZY
HDMI CN38 ns
p
ns
p
CONN.
17P FPC WAFER
CJP17GA193ZY
HDMI CN82 ns
p
ns
p
CONN.
15P WAFER FFC FCZ100E-15RSK
CJP15GB113ZY
HDMI CN84 ns
p
ns
p
CONN.
13P WAFER CARD CABLE
CJP13GB113ZY
HDMI D133 00MHZ20039050 00MHZ20039050 DIODE
1SS378
CVD1SS378
HDMI D901 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
HDMI D902 ns
p
90M-HD201750R DIODE
1N4003
CVD1N4003SRT
HDMI IC11 00D2623721007 00D2623721007 IC
SII9185CTU
CVISII9185CTU
HDMI IC12 90M-HC109780R 90M-HC109780R IC
AT24C02NSU EEPROM(2K)
CVIAT24C02NSU18
HDMI IC13 90M-HC400080R 90M-HC400080R IC
TC7MZ4052FK 4CH MUX
CVITC7MZ4052FK
HDMI IC14 90M-HC700680R 90M-HC700680R IC
TC74VHCT14AF
CVITC74VHCT14AFT
HDMI IC15 90M-HC700630R 90M-HC700630R IC
TC74VHCT04AFN
CVITC74VHCT04AFN
HDMI IC31 ns
p
ns
p
IC
SII9135CTU HDMI RX 144PIN TQFP
CVISII9135CTU
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
