Marantz AV8003 - Page 177

P.W.B.
NAME
POS. NO.
VERS.
COLOR
PART NO.
(FOR EUR)
PART NO.
(MZ)
PART NAME DESCRIPTION
HDMI IC32 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC33 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC34 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC36 00D2623719006 00D2623719006 IC
SII9134CTU HDMI TX 100PIN
CVISII9134CTU
HDMI
IC37
90M HC300830R
90M HC300830R
IC
RN RZ BA
HDMI
IC37
90M
-
HC300830R
90M
-
HC300830R
IC
RN
5
RZ
50
BA
HVIRN5RZ50BA
HDMI IC38 00D2623719006 00D2623719006 IC
SII9134CTU HDMI TX 100PIN
CVISII9134CTU
HDMI IC39 90M-HC300830R 90M-HC300830R IC
RN5RZ50BA
HVIRN5RZ50BA
HDMI IC40 943234001640S 943234001640S IC
TC7SH125FU
CVITC7SH125FU
HDMI IC51 239710004602S 239710004602S IC
SCALER(100PIN PQFP)
CVIABT1010M
HDMI IC52 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC53 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC54 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC55 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI
IC56
90M-HC700650R
90M-HC700650R
IC
TC74VCX541FT
CVITC74VCX541FT
HDMI
IC56
90M-HC700650R
90M-HC700650R
IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC57 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC58 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC59 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC61 90M-HC108830R 90M-HC108830R IC
NJM2285M
HVINJM2285MTE1
HDMI IC62 00D2623495003 00D2623495003 IC
ADV7403BSTZ-110 VIDEO ENCODER
CVIADV7403BS110
HDMI IC63 00MHC10019660 00MHC10019660 IC
CD0040AF
HVICD0040AF
HDMI IC64 90M-HC108970R 90M-HC108970R IC
HY57V161610ET-7
HVI57V161610ET7
HDMI IC65 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC66 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC67 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC68 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC69 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC70 90M-HC700650R 90M-HC700650R IC
TC74VCX541FT
CVITC74VCX541FT
HDMI IC71 00D2623478004 00D2623478004 IC
ADV7320KSTZ
CVIADV7320KSTZ
HDMI IC72 00MHC008205K0 00MHC008205K0 IC
TC74VHC08FT
CVITC74VHC08FT
HDMI IC81 943243001600M 943243001600M U-PRO
HD64F36049HV HDMI AV8003
CVIHD64F36049HV
HDMI 00M46CW499B00 00M46CW499B00 SOFTWARE
FIRMWARE FOR IC81
HDMI IC82 90M-HC700630R 90M-HC700630R IC
TC74VHCT04AFN
CVITC74VHCT04AFN
HDMI IC88 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC89 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC90 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC91 00D2631213905 00D2631213905 IC
KIA7808AF
CVIKIA7808AF
HDMI IC92 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC93 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC94 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC95 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC96 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI
IC97
90M HC900170R
90M HC900170R
IC
KIA1117S00 RTK/P
CVIKIA1117S00
HDMI
IC97
90M
-
HC900170R
90M
-
HC900170R
IC
KIA1117S00
-
RTK/P
CVIKIA1117S00
HDMI IC98 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI IC99 90M-HC900170R 90M-HC900170R IC
KIA1117S00-RTK/P
CVIKIA1117S00
HDMI JK11 90M-YT005010R 90M-YT005010R TERMINAL
HDMI YKF45-7009
HJJ9H003Z
HDMI JK12 90M-YT005010R 90M-YT005010R TERMINAL
HDMI YKF45-7009
HJJ9H003Z
HDMI JK13 90M-YT005010R 90M-YT005010R TERMINAL
HDMI YKF45-7009
HJJ9H003Z
HDMI JK14 90M-YT005010R 90M-YT005010R TERMINAL
HDMI YKF45-7009
HJJ9H003Z
HDMI JK31 90M-YT005010R 90M-YT005010R TERMINAL
HDMI YKF45-7009
HJJ9H003Z
HDMI JK32 90M-YT005010R 90M-YT005010R TERMINAL
HDMI YKF45-7009
HJJ9H003Z
HDMI L1
0
1
90
M-L
U000
2
90
R
90
M-L
U000
2
90
R
C
HIP IND
UC
T
MIP3226D100M 10UH
CLQ10E100MRY
0
90 U000 90
90 U000 90
C UC
HDMI L102 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L103 90M-LU000290R 90M-LU000290R CHIP INDUCT
MIP3226D100M 10UH
CLQ10E100MRY
HDMI L301 90M-LU000290R 90M-LU000290R CHIP INDUCT
MIP3226D100M 10UH
CLQ10E100MRY
HDMI L302 90M-LU000290R 90M-LU000290R CHIP INDUCT
MIP3226D100M 10UH
CLQ10E100MRY
HDMI L303 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L304 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L305 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L306 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L307 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L308 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L309 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L310 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L311 90M-FC900400R 90M-FC900400R FERRITE CORE
BEAD CHIP 60(1608 SIZE)
CLZ9R005Z
HDMI L312 90M-LU000290R 90M-LU000290R CHIP INDUCT
MIP3226D100M 10UH
CLQ10E100MRY
HDMI L313 90M-LU000290R 90M-LU000290R CHIP INDUCT
MIP3226D100M 10UH
CLQ10E100MRY
HDMI L314 90M-LU000290R 90M-LU000290R CHIP INDUCT
MIP3226D100M 10UH
CLQ10E100MRY
NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
213
