FRONT
REF No. Part No. Part Name Remarks Q'ty New Ver
R3930,3931 nsp RM73B--474JT +1608 00D2472013982 2
CAPACIITORS GROUP
C1001 nsp C1608X7R1H104K 00MDK9610430Y 1
C1003-1005 nsp C1608X7R1H104K 00MDK9610430Y 3
C1006 13405014840AS CE04W1J100MT(KR3) 13405014840AS 1
C1007 13405014940AS CE04W1J101MT(KR3) 13405014940AS 1
C1008 nsp C1608X7R1H104K 00MDK9610430Y 1
C1011,1012 nsp C1608X7R1H104K 00MDK9610430Y 2
C1014-1016 nsp C1608X7R1H104K 00MDK9610430Y 3
C1018 nsp CC73CH1H102JT +1608 00D2570508988 1
C1020 nsp C1608X7R1H104K 00MDK9610430Y 1
C1022 nsp C1608X7R1H104K 00MDK9610430Y 1
C1024 13405014940AS CE04W1J101MT(KR3) 13405014940AS 1
C1025,1026 nsp CK73B1H222KT +1608 00D2570509990 2
C1027 nsp C1608X7R1H104K 00MDK9610430Y 1
C1028 13405014840AS CE04W1J100MT(KR3) 13405014840AS 1
C1029,1030 nsp C1608X7R1H104K 00MDK9610430Y 2
C1031 nsp CC73CH1H102JT +1608 00D2570508988 1
C1033 nsp C1608X7R1H104K 00MDK9610430Y 1
C1034 nsp CC73CH1H102JT +1608 00D2570508988 1
C1038 nsp CC73CH1H101JT +1608 00D2570506951 1
C1040 nsp CC73CH1H101JT +1608 00D2570506951 1
C1042 nsp CC73CH1H101JT +1608 00D2570506951 1
C1043 nsp C1608X7R1H104K 00MDK9610430Y 1
C1046,1047 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C1048,1049 nsp C1608X7R1H104K 00MDK9610430Y 2
C1050 nsp CC73CH1H101JT +1608 00D2570506951 1
C1051,1052 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C1053 nsp CC73CH1H102JT +1608 00D2570508988 1
C1055 nsp CC73CH1H330JT +1608 00D2570504940 1
C1056 13405014840AS CE04W1J100MT(KR3) 13405014840AS 1
C1058 nsp CC73CH1H102JT +1608 00D2570508988 1
C1059,1060 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C1061 nsp CC73CH1H102JT +1608 00D2570508988 1
C1064,1065 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C1066 13405012940AS CE04W1C101MT(KR3) 13405012940AS 1
C1067,1068 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C1069,1070 nsp CC73CH1H331JT +1608 00D2570507976 2
C1072 nsp C1608X7R1H104K 00MDK9610430Y 1
C1073 13405014840AS CE04W1J100MT(KR3) 13405014840AS 1
C1075-1078 nsp C1608X7R1H104K 00MDK9610430Y 4
C1080,1081 nsp C1608X7R1H104K 00MDK9610430Y 2
C1086,1087 nsp C1608X7R1H104K 00MDK9610430Y 2
C1090,1091 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C1096 13405014840AS CE04W1J100MT(KR3) 13405014840AS 1
C1098 nsp CC73CH1H102JT +1608 00D2570508988 1
C1099-1101 nsp CC73CH1H101JT +1608 00D2570506951 3
C1102 nsp C1608X7R1H104K 00MDK9610430Y 1
C1108,1109 nsp CC73CH1H102JT +1608 00D2570508988 2
C1110 nsp C1608X7R1H104K 00MDK9610430Y 1
C1112 nsp C1608X7R1H104K 00MDK9610430Y 1
C1120-1122 133050090557S CQ93P2A104JT(PPF)
133050090557S 3
C3901 nsp CC73CH1H102JT +1608 00D2570508988 1
C3907,3908 nsp CC73CH1H221JT +1608 00D2570507934 2
C3914,3915 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C3919,3920 13405012440AS CE04W0J221MT(KR3) 13405012440AS 2
C3921,3922 nsp CC73CH1H101JT +1608 00D2570506951 2
C3923,3924 nsp CK73B1E223KT +1608 00D2570516909 2
C3925,3926 nsp CK73B1H682KT +1608 00D2570510950 2
C3927,3928 13405014840AS CE04W1J100MT(KR3) 13405014840AS 2
C3931,3932 13405013240AS CE04W1E470MT(KR3) 13405013240AS 2
OTHER PARTS GROUP
B0904-0906 nsp GND TERMINAL FOR PCB 00MYL01010241 3
B1002 nsp SRA21T3-SOLD AWG20 UL1015 00MYB00091620 1
B3901 nsp M3 SCREW TERMINAL 00D2051034007 1
! F1001 65205003540AS FUSE(SCT250MA) 65205003540AS 1
K1001 643010087005S H/P JACK(PJ-612A)-NI-BK 643010087005S 1
K1002 643010088008S MINI JACK(PJ-310HA-7)-NI 643010088008S 1
K1003 64301019700AS 3P PIN JACK(RCA-328H)-NI-BK 64301019700AS 1
K3901 64301000710AS 2PIN PIN JACK(RCA-206BG-00-05)-AU-RD/WH 64301000710AS 1
N0101 nsp B14B-PH-K-S (LF)(SN) 00MYJ06006340 1
N0102 nsp B9B-PH-K-S (LF)(SN) 00MYJ06006290 1
N0103 nsp B12B-PH-K-S (LF)(SN) 00MYJ06006320 1
N0104 nsp B11B-PH-K-S (LF)(SN) 00MYJ06006310 1
N0105 nsp B15B-PH-K-S (LF)(SN) 00MYJ06006350 1
N0106-0118 nsp 9P PLUG(C125Z1) 645010067014S 13
N0119 nsp B3B-EH 3P 00MYP06003830 1
N0120 nsp B16B-PH-K-S (LF)(SN) 00MYJ06006360 1
N0121 nsp B10B-PH-K-S (LF)(SN) 00MYJ06006300 1
N1001 nsp S7B-EH 00MYP06003960 1
N1002 nsp B7B-PH-K-S (LF)(SN) 00MYJ06006270 1
N1006 nsp B5B-PH-K-S (LF)(SN) 00MYJ06006250 1
N1009 nsp S5B-PH-K-S (LF)(SN) 00MYJ06006450 1
N1012 nsp 40FMN-BTRK-A(LF)(SN) 645010077004S 1
N1013 nsp S3B-PH-K-S (LF)(SN) 00MYJ06006430 1
N1015 nsp B3B-PH-K-S (LF)(SN) 00MYJ06006230 1
N3902 nsp 7P SOCKET(C125Z2) 645010068000S 1
S1001-1023 00D2125611903 TACT SWITCH(TAPE H5) 00D2125611903 23
S1024 665010017006S PUSH SW(SSCT101) 665010017006S 1
S1026 663010005007S ROT.ENCODER(EC16B24S0-ZZZ) 663010005007S 1
S1027 663010006000S ROT.ENCODER(EC16B24T01D4ZZZ) 663010006000S 1
Z1002 172010008005S VFD(GP1261AI) 172010008005S 1
Z1003 17201001300AS FLD(17-BT-40GINK) 17201001300AS 1
Z1006 nsp BUFFER 47151003801AM 1
Z9001 nsp HOLDER FLD SR7005 A332 454310041008M 1
Z9002,9003 nsp RUBBER SHEET 00D4610991042 2
