FRONT
FRONT PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
D1001 26301020310AS WEJ3290W-R2H0-BA(GREEN/RED LED) 26301020310AS 1 *
D1002,1003 20305002730AS 1N4003(HOMI) 20305002730AS 2
D1004 00D2760798948 UDZS8.2B-TE17 00D2760798948 1
D1016 00D2760848908 UDZS22B-TE17 00D2760848908 1
D1017 00D2760798935 UDZS20B-TE17 00D2760798935 1
D1026 00D2760683930 UDZS5.1B-TE17 +C 00D2760683930 1
D1027,1028 263010046507S BL-BUF4V5K-1-AV-FP3.5-TBF19.5C 263010046507S 2
D1029,1030 263010047500S TOL-52CSBBCEA-B2 263010047500S 2
D1031,1032 00D2760683930 UDZS5.1B-TE17 +C 00D2760683930 2
D1033,1034 263010047500S TOL-52CSBBCEA-B2 263010047500S 2
D1040-1042 20305002730AS 1N4003(HOMI) 20305002730AS 3
Q1001 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q1004 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q1005 21385001950AS 2SC5810 21385001950AS 1
Q1006 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q1008 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q1011 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q1012 00D2710316901 KTA1042D-Y-RTF/P 00D2710316901 1
Q1014-1016 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 3
Q1017 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q1018 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
U1002 23181012550AS NJM2887DL3-TE2 23181012550AS 1
U1004 262010007707S R94EV1A 262010007707S 1
U1006,1007 23281004250AS NJM8068G-TE2 23281004250AS 2
U3902 23281004250AS NJM8068G-TE2 23281004250AS 1
RESISTOR GROUP
R1003 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1006 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1007 nsp RM73B--102JT +1608 00D2472007943 1
R1008 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1009,1010 nsp RM73B--221JT +1608 00D2472005987 2
R1011 nsp RM73B--102JT +1608 00D2472007943 1
R1012 nsp RM73B--473JT +1608 00D2472011942 1
R1013 nsp RM73B--102JT +1608 00D2472007943 1
R1014 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1015 nsp RM73B--010KT +1608 00D2472018916 1
R1016 nsp RM73B--101JT +1608 00D2472005903 1
R1017 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R1018 nsp RM73B--010KT +1608 00D2472018916 1
R1019 nsp RM73B--2R2KT +1608 00D2472001907 1
R1020 nsp RM73B--101JT +1608 00D2472005903 1
R1022 nsp RM73B--104JT +1608 00D2472012925 1
R1023 nsp RM73B--154JT +1608 00D2472012967 1
R1024 nsp RM73B--623JT +1608 00D2472011971 1
R1025 nsp RM73B--473JT +1608 00D2472011942 1
R1027 nsp RM73B--101JT +1608 00D2472005903 1
R1034 nsp RM73B--393JT +1608 00D2472011926 1
R1037 nsp RM73B--104JT +1608 00D2472012925 1
R1038 nsp RM73B--101JT +1608 00D2472005903 1
R1039-1042 nsp RM73B--100JT +1608 00D2472002964 4
R1044 nsp RM73B--104JT +1608 00D2472012925 1
R1046 nsp RM73B--124JT +1608 00D2472012941 1
R1047 nsp RM73B--243JT +1608 00D2472010972 1
R1048 nsp RM73B--222JT +1608 00D2472008926 1
R1049-1051 nsp RM73B--820JT +1608 00D2472004988 3
R1052 nsp RM73B--104JT +1608 00D2472012925 1
R1054 nsp RM73B--101JT +1608 00D2472005903 1
R1055 nsp RM73B--103JT +1608 00D2472009983 1
R1056 nsp RM73B--0R0KT +1608 00D2472018903 1
R1057 nsp RM73B--102JT +1608 00D2472007943 1
R1058-1060 nsp RM73B--0R0KT +1608 00D2472018903 3
R1063 nsp RM73B--0R0KT +1608 00D2472018903 1
R1064 nsp RM73B--561JT +1608 00D2472006986 1
R1065 nsp RM73B--0R0KT +1608 00D2472018903 1
R1066-1068 nsp RM73B--101JT +1608 00D2472005903 3
R1069 nsp RM73B--122JT +1608 00D2472007969 1
R1070 nsp RM73B--102JT +1608 00D2472007943 1
R1072 nsp RM73B--333JT +1608 00D2472011900 1
R1076 nsp RM73B--101JT +1608 00D2472005903 1
R1077 nsp RM73B--122JT +1608 00D2472007969 1
R1079-1081 nsp RM73B--271JT +1608 00D2472006915 3
R1082 nsp RM73B--473JT +1608 00D2472011942 1
R1083 nsp RM73B--151JT +1608 00D2472005945 1
R1084,1085 nsp RM73B--221JT +1608 00D2472005987 2
R1086 nsp RM73B--103JT +1608 00D2472009983 1
R1087 nsp RM73B--151JT +1608 00D2472005945 1
R1088,1089 nsp RM73B--331JT (1608) +1608 00D2472006902 2
R1090 nsp RM73B--103JT +1608 00D2472009983 1
R1097,1098 nsp RM73B--561JT +1608 00D2472006986 2
R1099,1100 nsp RM73B--103JT +1608 00D2472009983 2
R1101 nsp RM73B--151JT +1608 00D2472005945 1
R1102,1103 nsp RM73B--101JT +1608 00D2472005903 2
R1104 nsp RM73B--151JT +1608 00D2472005945 1
R1105 nsp RM73B--221JT +1608 00D2472005987 1
R1106 nsp RM73B--561JT +1608 00D2472006986 1
R1108 nsp RM73B--331JT (1608) +1608 00D2472006902 1
R1109 nsp RM73B--821JT +1608 00D2472007927 1
R1110,1111 nsp RM73B--563JT +1608 00D2472011968 2
R1112,1113 nsp RM73B--474JT +1608 00D2472013982 2
R1114,1115 nsp RM73B--471JT +1608 00D2472006960 2
R1116 nsp RM73B--101JT +1608 00D2472005903 1
R1119-1122 nsp RM73B--472JT (1608) +1608 00D2472009909 4
R1125 nsp RM73B--391JT +1608 00D2472006944 1
R1126 nsp RM73B--301JT +1608 00D2472006928 1
R1134,1135 nsp RM73B--103JT +1608 00D2472009983 2
R1141 nsp RM73B--473JT +1608 00D2472011942 1
R3902,3903 nsp RM73B--0R0KT +1608 00D2472018903 2
R3904,3905 nsp RM73B--391JT +1608 00D2472006944 2
R3906,3907 nsp RM73B--683JT +1608 00D2472011984 2
R3908,3909 nsp RM73B--154JT +1608 00D2472012967 2
R3912,3913 nsp RM73B--271JT +1608 00D2472006915 2
R3917,3918 nsp RM73B--470JT +1608 00D2472004920 2
R3922,3923 nsp RM73B--154JT +1608
00D2472012967 2
R3924,3925 nsp RM73B--123JT +1608 00D2472010901 2
R3926,3927 nsp RM73B--470JT +1608 00D2472004920 2
