HDAM

HDAM PCB ASS'Y

※Parts indicated b

"ns

"on this table cannot be su

lied

※The

arts listed below are onl

for maintenance. Therefore the

ht differ from the

arts used in the unit in a

earances or dimension

NOTE:The symbols in the column Remarks indicate the following destinations.

U : North America model N : Europe model K : China model F : Japan model

B : Black model SG : Silver Gold model

REF No. Part No. Part Name Remarks Q'ty New Ver

SEMICONDUCTORS GROUP

D3804,3805 00D2760683998 UDZS16B-TE17 +C 00D2760683998 2

D3806,3807 251310004507S CG0603MLC-12LE 251310004507S 2

D3851,3852 00D2760794900 KDS160-RTK/P 00D2760794900 2

D3853 00MHI20002210 SIR-34ST3F 00MHI20002210 1

D4001,4002 00D2760794900 KDS160-RTK/P 00D2760794900 26

D5001,5002 00D2760794900 KDS160-RTK/P 00D2760794900 26

D5559-5561 251310004507S CG0603MLC-12LE 251310004507S 3

Q3801,3802 00D2710260905 2SA1036KT146(S/R) +C 00D2710260905 2

Q3803,3804 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 2

Q3851 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1

Q3852 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1

Q3853 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1

Q3854-3856 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 3

Q4001 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 13

Q4002,4003 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 26

Q4004,4005 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 26

Q4006 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 13

Q4007 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 13

Q4008,4009 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 26

Q4010 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 13

Q5001 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 13

Q5002,5003 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 26

Q5004,5005 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 26

Q5006 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 13

Q5007 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 13

Q5008,5009 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 26

Q5010 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 13

Q5501 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1

Q5502 00D2690193901 KRC104S-RTK/P (47K-47K) 00D2690193901 1

Q6007 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 13

Q6008,6009 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 26

Q6010 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 13

U0504 23281004250AS NJM8068G-TE2 23281004250AS 1

U0506,0507 23281004250AS NJM8068G-TE2 23281004250AS 2

U3801 236810090504S ILX3232D 236810090504S 1

U3803,3804 262010006704S JSR1165 262010006704S 2

U3805 23381001150AS SN74AHCU04D 23381001150AS 1

U3851 262010007707S R94EV1A 262010007707S 1

U5501 236810064604S AD8195ACPZ 236810064604S 1

RESISTOR GROUP

R0107,0108 00MGG0510016X 10 OHM +- 5% 1/6W 00MGG0510016X 26

R0529,0530 nsp RM73B--103JT +1608 00D2472009983 2

R0533 nsp RM73B--101JT +1608 00D2472005903 1

R0534-0536 nsp RM73B--222JT +1608 00D2472008926 3

R0537 nsp RM73B--101JT +1608 00D2472005903 1

R0538 nsp RM73B--222JT +1608 00D2472008926 1

R0551-0558 nsp RM73B--222JT +1608 00D2472008926 8

R0569,0570 nsp RM73B--563JT +1608 00D2472011968 2

R0573,0574 nsp RM73B--563JT +1608 00D2472011968 2

R0584 nsp RM73B--101JT +1608 00D2472005903 1

R0585,0586 nsp RM73B--564JT +1608 00D2472014907 2

R0587,0588 nsp RM73B--101JT +1608 00D2472005903 2

R0589,0590 nsp RM73B--564JT +1608 00D2472014907 2

R0591 nsp RM73B--101JT +1608 00D2472005903 1

R3801-3804 nsp RM73B--0R0KT +1608 00D2472018903 4

R3805-3808 nsp RM73B--684JT +1608 00D2472014923 4

R3809 nsp RM73B--101JT +1608 00D2472005903 1

R3810,3811 nsp RM73B--472JT (1608) +1608 00D2472009909 2

R3812,3813 nsp RM73B--101JT +1608 00D2472005903 2

R3814,3815 nsp RM73B--102JT +1608 00D2472007943 2

R3816 nsp RM73B--101JT +1608 00D2472005903 1

R3828,3829 nsp RM73B--102JT +1608 00D2472007943 2

R3832 nsp RM73B--330JT +1608 00D2472003989 1

R3833,3834 nsp RM73B--750JT +1608 00D2472004975 2

R3837,3838 nsp RM73B--330JT +1608 00D2472003989 2

R3839,3840 nsp RM73B--471JT +1608 00D2472006960 2

R3845,3846 nsp RM73B--473JT +1608 00D2472011942 2

R3847,3848 nsp RM73B--334JT +1608 00D2472013940 2

R3851,3852 nsp RM73B--330JT +1608 00D2472003989 2

R3853,3854 nsp RM73B--102JT +1608 00D2472007943 2

R3855 nsp RM73B--470JT +1608 00D2472004920 1

R3856 nsp RM73B--473JT +1608 00D2472011942 1

R3857 nsp RM73B--183JT +1608 00D2472010943 1

R3858-3860 nsp RM73B--101JT +1608 00D2472005903 3

R3861 nsp RM73B--333JT +1608 00D2472011900 1

R3862 nsp RM73B--101JT +1608 00D2472005903 1

R4001 nsp RM73B--333JT +1608 00D2472011900 13

R4002 nsp RM73B--151JT +1608 00D2472005945 13

R4003,4004 nsp RM73B--220JT +1608 00D2472003947 26

R4005,4006 nsp RM73B--912JT +1608 00D2472009970 26

R4007,4008 nsp RM73B--471JT +1608 00D2472006960 26

R4009,4010 nsp RM73B--220JT +1608 00D2472003947 26

R4011,4012 nsp RM73B--331JT (1608) +1608 00D2472006902 26

R4013 nsp RM73B--105JT +1608 00D2472014965 13

R4014,4015 nsp RM73B--220JT +1608 00D2472003947 26

R4016 nsp RM73B--101JT +1608 00D2472005903 13

R4017,4018 nsp RM73B--912JT +1608 00D2472009970 26

R4019,4020 nsp RM73B--220JT +1608 00D2472003947 26

R4021 nsp RM73B--101JT +1608 00D2472005903 13

R4022 nsp RM73B--0R0KT +1608 00D2472018903 13

R4031 nsp RM73B--104JT +1608 00D2472012925 13

R5002 nsp RM73B--222JT +1608 00D2472008926 13

R5003,5004 nsp RM73B--220JT +1608 00D2472003947 26

R5005,5006 nsp RM73B--912JT +1608 00D2472009970 26

R5007,5008 nsp RM73B--471JT +1608 00D2472006960 26

R5009,5010 nsp RM73B--220JT +1608 00D2472003947 26

R5011,5012 nsp RM73B--331JT (1608) +1608 00D2472006902 26

R5013 nsp RM73B--105JT +1608 00D2472014965 13

R5014,5015 nsp RM73B--220JT +1608 00D2472003947 26

R5016 nsp RM73B--222JT +1608 00D2472008926 13

R5017,5018 nsp RM73B--912JT +1608

00D2472009970 26

R5019,5020 nsp RM73B--220JT +1608 00D2472003947 26

R5021 nsp RM73B--101JT +1608 00D2472005903 13

R5501 nsp RM73B--102JT 00D2473008941 1

R5502 nsp RM73B--103JT +1005 00D2473010984 1
