Marantz AV8802/U1B - Page 214

HDAM
REF No. Part No. Part Name Remarks Q'ty New Ver
R5503 nsp RM73B--473JT+1005 00D2473012940 1
R5505,5506 nsp RM73B--0R0KT +1608 00D2472018903 2
R5508,5509 nsp RM73B--103JT +1005 00D2473010984 2
R5510,5511 nsp RM73B--0R0KT+1005 00D2473001906 2
R5515 nsp RM73B--0R0KT+1005 00D2473001906 1
R5516-5519 nsp MNR02=000(1005X2) 12625000450AS 4
R5559 nsp RM73B--222JT +1608 00D2472008926 1
R6014,6015 nsp RM73B--220JT +1608 00D2472003947 26
R6016 nsp RM73B--101JT +1608 00D2472005903 13
R6017,6018 nsp RM73B--912JT +1608 00D2472009970 26
R6019,6020 nsp RM73B--220JT +1608 00D2472003947 26
R6021 nsp RM73B--471JT +1608 00D2472006960 13
R6031 nsp RM73B--104JT +1608 00D2472012925 13
CAPACIITORS GROUP
C0511,0512 00D2544574919 CE04W1H470MT(RA3) 00D2544574919 2
C0515 00D2544574919 CE04W1H470MT(RA3) 00D2544574919 1
C0516,0517 nsp CC73CH1H101JT +1608 00D2570506951 2
C0518 00D2544574919 CE04W1H470MT(RA3) 00D2544574919 1
C0519,0520 nsp CC73CH1H101JT +1608 00D2570506951 2
C0541-0544 nsp CC73CH1H101JT +1608 00D2570506951 4
C0547-0549 00D2544574919 CE04W1H470MT(RA3) 00D2544574919 3
C0550,0551 nsp CC73CH1H221JT +1608 00D2570507934 2
C0552 00D2544574919 CE04W1H470MT(RA3) 00D2544574919 1
C0553,0554 nsp CC73CH1H221JT +1608 00D2570507934 2
C3801 nsp CC73CH1H102JT +1608 00D2570508988 1
C3803 nsp CC73CH1H102JT +1608 00D2570508988 1
C3804,3805 nsp CK73B1H102KT +1608 00D2570509929 2
C3807-3809 nsp CC73CH1H221JT +1608 00D2570507934 3
C3810,3811 nsp CK73B1H102KT +1608 00D2570509929 2
C3812,3813 nsp CK73B1E104KT +1608 00D2570516954 2
C3814 nsp CC73CH1H221JT +1608 00D2570507934 1
C3816,3817 nsp CC73CH1H330JT +1608 00D2570504940 2
C3829 nsp CK73B0J475KT +1608 00D2570522906 1
C3830 nsp CK73B1E104KT +1608 00D2570516954 1
C3833-3839 nsp CK73B1E104KT +1608 00D2570516954 7
C3840,3841 nsp CK73B1H102KT +1608 00D2570509929 2
C3842,3843 nsp CK73B1H103KT (1608) +1608 00D2570501901 2
C3844 nsp CK73B1E104KT +1608 00D2570516954 1
C3845 nsp CK73B1H102KT +1608 00D2570509929 1
C3851,3852 nsp CK73B1E104KT +1608 00D2570516954 2
C3854-3856 nsp CK73B0J475KT +1608 00D2570522906 3
C4001 00D2544573994 CE04W1H220MT(RA3) 00D2544573994 13
C4002,4003 nsp CC73CH1H221JT +1608 00D2570507934 26
C4004,4005 00D2544569937 CE04W1E221MT(RA3) 00D2544569937 26
C4006 00D2544573994 CE04W1H220MT(RA3) 00D2544573994 13
C5001 00D2544574919 CE04W1H470MT(RA3) 00D2544574919 13
C5003 nsp CC73CH1H221JT +1608 00D2570507934 13
C5501 nsp CK73B1E104KT +1608 00D2570516954 1
C5502-5505 nsp CK73B1A104KT +1005 00D2575008933 4
C5506 nsp CK73X5R0J106MT(2125) 132450038507S 1
C5507 nsp CK73B1H102KT +1005 00D2575006993 1
C5508 nsp CK73B1E103KT(1005)
00D2575008946 1
C5509 nsp CK73B1H102KT +1005 00D2575006993 1
C5510-5520 nsp CK73X5R0J106MT(2125) 132450038507S 11
C5560 nsp CK73B1E104KT +1608 00D2570516954 1
C5561 00D2544645903 CE67C0J221MT(MVA) +REF 00D2544645903 1
C6006 00D2544573994 CE04W1H220MT(RA3) 00D2544573994 13
OTHER PARTS GROUP
B0101,0102 nsp M3 SCREW TERMINAL 00D2051034010 26
K3801 64301021100AS XLR CONNECTOR (XLR-22) 64301021100AS 1
K3802,3803 643010086019S MINI JACK(PJ-308-02(RD)) 643010086019S 2
K3804 64301021100AS XLR CONNECTOR (XLR-22) 64301021100AS 1
K3806 64601001802AS 2P PIN JACK(MSD-252V)-AU-BK 64601001802AS 1
K3851 643010084006S 2P PINJACK(RCA-206B)-NI-O 643010084006S 1
K3852 643010086002S MINI JACK(PJ-308-02) 643010086002S 1
K5501 64401030160AS A0D7ABAR19N0 64401030160AS 1
L3803 nsp E.FIL(BLM21PG221SN1)+2125 00D2350147909 1
L5559 113410007504S DLW21SN181SQ2L 113410007504S 1
L5560 nsp E.FIL(BLM21PG221SN1)+2125 00D2350147909 1
N0101 nsp 9P SOCKET(C125Z2) 645010068017S 13
N0504 nsp B5B-PH-K-S (LF)(SN) 00MYJ06006250 1
N3801 64301017200AS 9P D-SUB CONNECTOR(D227FD009S100BY) 64301017200AS 1
N3803 nsp 19P FFC BASE (P=1) 00D2050892020 1
N3851 nsp B8B-PH-K-S (LF)(SN) 00MYJ06006280 1
N5501 nsp 25P FFC.BASE(9610SCA +REF 00D2051313906 1
N5559 00D2051381103 USB CONNECTOR 00D2051381103 1
N5560 nsp B5B-PH-K-S (LF)(SN) 00MYJ06006250 1
N9016,9017 nsp 7P PLUG(C125Z1) 645010067007S 2
Z3851 nsp SHIELD CASE FLASHER SR7005 A332 445310117000M 1
Z3852-3854 nsp STYLE PIN 00D2050452017 3
★
nsp
EARTH PLATE(8802)
This Parts list describes the product with the following serial No.
A
V8802A N1B : ABD15161201741 or late
r
For NEW FRONT
HDMI USB PCB N
ONL
Y
44431055700AS 1 * 6
