Paths conrmation item Display Settings Contents of conrmation Remarks
6
A/D
(MAIN ZONE)
A 0 6 : A D
Input Source : CBL/SAT
Input Mode : Analog(xed)
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers=2 Height Speakers
Height Layout=Front Height
Speaker Select : Floor
Speaker Cong : All Speaker=Small/Subwoofer=2spkrs
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ RCA output (Front L/R, Center, Surround L/R, Surround Back L/R, Front Wide L/R, Subwoofer)
・ Analog input ⇒ XLR output, SW(20Hz) (Front L/R, Center, Surround L/R, Surround Back L/R, Front Wide L/R, Subwoof-
er)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
7
Amp Assign
(ZONE2)
A 0 7 : A S S I G N - Z 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 11.1ch
ZONE2 : ON
Z2 Source : Source
Z2 Vol : 60（-20dB)
ZONE3 : OFF
・Analog input ⇒ ZONE 2 RCA output (ZONE2 L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
8
Amp Assign
(ZONE3)
A 0 8 : A S S I G N - Z 3
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Amp assign : 11.1ch
ZONE2 : OFF
ZONE3 : ON
ZONE3 Source : Source
Z3 Vol. : 60.0（-20.0dB）
・Analog input ⇒ ZONE 3 RCA output (ZONE3 L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
9
Amp Assign
(BiAMP-Surround Back)
A 1 1 : B i A m p - S B
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Vol. : 60.0 (-20.0dB)
Amp assign : 9.1ch(Bi-Amp)
Speaker for Bi-Amp : SURROUND BACK
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
・Analog input ⇒ RCA output (Front L/R, Surround Back L/R → Front)
・Analog input ⇒ XLR output (Front L/R, Surround Back L/R → Front)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
10
Amp Assign
(BiAMP-Front Wide)
A 1 2 : B i A m p - S W
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Vol. : 60.0 (-20.0dB)
Amp assign : 9.1ch (Bi-Amp)
Speaker for Bi-Amp : FRONT WIDE
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
・Analog input ⇒ RCA output (Front L/R, Front Wide L/R → Front)
・Analog input ⇒ XLR output (Front L/R, Front Wide L/R → Front)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
11
Amp Assign
(BiAMP-Height1)
A 1 3 : B i A m p - H 1
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Stereo
Vol. : 60.0 (-20.0dB)
Amp assign : 9.1ch (Bi-Amp)
Speaker for Bi-Amp : HEIGHT1
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
・Analog input ⇒ RCA output (Front L/R, Height1 L/R → Front)
・Analog input ⇒ XLR output (Front L/R, Height1 L/R → Front)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
12
Front Height
A 1 4 : F R O N T H E I G H T
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers : 4Height Speakers
Height Layout : Top Front & Top Rear
Speaker Cong : Front Wide=None
Speaker Select : Floor & Height
MAIN ZONE ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ RCA output (Height 1 L/R → Top Front, Height 2 L/R → Top Rear）
・Analog input ⇒ XLR output (Height 1 L/R → Top Front, Height 2 L/R → Top Rear)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
