Paths conrmation item Display Settings Contents of conrmation Remarks
13
Front Wide
A 1 5 : F R O N T W I D E
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi Ch Stereo
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Height Speakers : 4 Height Speakers
Height Layout : Front Height & Top Middle
Speaker Cong: S.Back=None
Speaker Select : Floor
MAIN ZONE ON
ZONE2 : OFF
ZONE3 : OFF
・Analog input ⇒ RCA output (Front Wide L/R）
・Analog input ⇒ XLR output (Front Wide L/R）
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
14
7.1CH IN
A 1 9 : 7 . 1 C H I N
Input Source : CBL/SAT
Input Mode : 7.1CH IN
Vol. : 60.0（-20.0dB）
Amp assign : 11.1ch
Speaker Cong : All Speaker=Small/Subwoofer=2spkrs
Speaker Select : Front, Center, Surround, S.Back, Subwoofer
MAIN ZONE ON
ZONE2 : OFF
ZONE3 : OFF
・7.1CH IN input ⇒ RCA output (Front L/R, Center, Surround L/R, S.Back L/R, Subwoofer)
・7.1CH IN input ⇒ XLR output (Front L/R, Center, Surround L/R, S. Back L/R, Subwoofer)
(
b
The input source can be switched to any source except CBL/SAT.）
15
Back DAC>>Height2
A 2 0 : S B - H E I G H T 2
Input Source : CBL/SAT
Input Mode : Auto
Sound mode : Multi ch Stereo
Vol. : 60.0 (-20.0dB)
Amp assign : 11.1ch
Height Speakers : 4Height Speakers
Height Layout : Top Front & Top Rear
Speaker Conog : Surround Back=None
Speaker Select : Floor & Height
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
・Analog 入力 ⇒ RCA 出力 (Height2 L/R → Top Rear)
・Analog 入力 ⇒ XLR 出力 (Height2 L/R → Top Rear)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
16
Height1 DAC>>Height2
A 2 1 : H 1 - H E I G H T 2
nput Source : CBL/SAT
Input Mode : Auto
Sound Mode : Multi ch Stereo
Vol. : 60.0 (-20.0dB)
Amp assign : 11.1ch
Height Speakers : 4 Height Speakers
Height Layout : Top Front & Top Rear
Speaker Conog : All Small
Speaker Select : Front
b
Special conguration :
Height1 Path → Fixed the Height1 RCA/XLR of Relay in Off
Height1 Path → Fixed the Height2 RCA/XLR of Relay in On
Back Path → Fixed the Height2 RCA/XLR of Relay in On
Back Path → Fixed the Height2 RCA/XLR of Relay in Off
Wide Path → Fixed the Wide RCA/XLR of Relay in On
Wide Path → Fixed the Height2 RCA/XLR of Relay in Off
MAIN ZONE ON
ZONE2 OFF
ZONE3 OFF
・Analog input ⇒ RCA 出力 ( Top Rear L/R)
・Analog input ⇒ XLR 出力 ( Top Rear L/R)
(
b
The input source can be switched to any source except CBL/SAT.）
(
b
Volume -20dB is the value when Relative settings are used. The value is 60 when Absolute settings are used）
Attention : For paths conrmation, in this mode, audio output of Height1 I will be output from the RCA/XLR of Height2.
(No sound is output from the Height1 of RCA / XLR. Sound of Height2 is not output from any terminal.)
g.13a
g.13b
g.14
g.15a
g.15b
g.16a
g.16b
