Marantz AV8802/U1B - Page 269

CX870 CONNECT for AV8802
CX870 CONNECT for AV8802 PCB ASS'Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied
.
※The
p
arts listed below are onl
y
for maintenance. Therefore the
y
mi
g
ht differ from the
p
arts used in the unit in a
pp
earances or dimension
s
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
SEMICONDUCTORS GROUP
U0001 23181020250AS BD00HA3WEFJ-E2 23181020250AS 1
U0002 00MHC012405KY TC7SGU04FE(TE85L F 00MHC012405KY 1
U0003 18901010200AS BT MODULE(IBT-06) 18901010200AS 1
U0902 23681012650AS NCP380HMU21AATBG 23681012650AS 1
U0903 231810089509S EX3AV 231810089509S 1
RESISTOR GROUP
R0001 nsp RM73B--393JT +1608 00D2472011926 1
R0002 nsp RM73B--113JT +1608 00D2472009996 1
R0003 nsp RM73B--103JT +1005 00D2473010984 1
R0004 nsp RM73B--106KT +1608 00D2472017904 1
R0005 nsp RM73B--824JT +1608 00D2472014949 1
R0006,0007 nsp RM73B--103JT +1005 00D2473010984 2
R0902-0905 nsp RM73B--0R0KT +1608 00D2472018903 4
R0909 nsp RM73B--102JT +1608 00D2472007943 1
R0915 nsp RM73B--103JT +1005 00D2473010984 1
R0963 nsp RM73B--0R0KT+1005 00D2473001906 1
R0964,0965 nsp RM73B--103JT +1005 00D2473010984 2
R0968-0971 nsp RM73B--0R0KT+1005 00D2473001906 4
R0972,0973 nsp RM73B--0R0KT +2125 00D2470018905 2
R0974 nsp RM73B--103JT +1005 00D2473010984 1
R0975 nsp RM73B--0R0KT+1005 00D2473001906 1
R0980-0982 nsp PRB3T4=0R0(1005X4) 126250001502S 3
R3603 nsp RM73B--473JT+1005 00D2473012940 1
R3626 nsp RM73B--154DT(1608) 00D2472038925 1
R3627 nsp RM73B--124DT(1608) 00D2472038909 1
R3631 nsp RM73B--514JT +1608 00D2472013995 1
R3659 nsp RM73B--100JT 00D2473003962 1
R9039,9040 nsp RM73B--0R0KT +1608 00D2472018903 2
CAPACIITORS GROUP
C0001 nsp CK73X5R0J106MT(2125) 132450038507S 1
C0002,0003 nsp CK73B1A105KT +1608 00D2570521907 2
C0004 nsp CC73CH1H220JT +1608 00D2570504908 1
C0005-0007 nsp CK73B1A104KT +1005 00D2575008933 3
C0008 nsp CC73CH1H270JT +1608 00D2570504924 1
C0020 nsp CK73B1H102KT +1608 00D2570509929 1
C0901 nsp CK73X5R0J106MT(2125) 132450038507S 1
C0907 nsp CK73B1A104KT +1005 00D2575008933 1
C0930 nsp CK73B1A104KT +1005 00D2575008933 1
C0951-0954 nsp CK73X5R0J106MT(2125) 132450038507S 4
C0996-0999 nsp CK73B1A104KT +1005 00D2575008933 4
C3603 nsp CK73B1A104KT +1005 00D2575008933 1
C3615 nsp CK73X5R0J106MT(2125) 132450038507S 1
C3619 nsp CK73B1E103KT(1005) 00D2575008946 1
C3623 nsp CK73B1A104KT +1005 00D2575008933 1
C3627 nsp CK73X5R0J106MT(2125) 132450038507S 1
C3633 nsp CK73X5R0J106MT(2125) 132450038507S 1
C3637 nsp CC73CH1H100DT +1005 00D2575002926 1
C3645 nsp CK73B1A104KT +1005 00D2575008933 1
C3649 nsp CK73B1H102KT +1005 00D2575006993 1
OTHER PARTS GROUP
B0901,0902 nsp M3 SCREW TERMINAL H=4.5 44431034300AD 2
L0001,0002 nsp E.FIL(BLM21PG221SN1)+2125 00D2350147909 2
L0901,0902 nsp E.FIL(BLM21PG221SN1)+2125 00D2350147909 2
L3601 nsp E.FIL(BLM21PG221SN1)+2125 00D2350147909 1
L3606 nsp E.FIL(BLM21PG221SN1)+2125 00D2350147909 1
N0001 nsp B11B-PH-K-S (LF)(SN) 00MYJ06006310 1
N0901 nsp S11B-PH-K-S (LF)(SN) 00MYJ06006510 1
N0902 nsp 120P(14 5046 120 645 829+) 64501020350AS 1
N0903 nsp S6B-PH-K-S (LF)(SN) 00MYJ06006460 1
N0905,0906 nsp 64P(S1262-64SVB-S02-1R) 64501020250AS 2
X0001 00MJX0000246Y TFX-02(32.768kHz) 00MJX0000246Y 1
nsp 3P SCN-5P SAN 130mm 61205064300AS 1
62
