EXPLODED
EXPLODED
※Parts indicated by "nsp"on this table cannot be supplied.
※The parts listed below are only for maintenance. Therefore they might differ from the parts used in the unit in appearances or dimensions.
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver Gold model
REF No. Part No. Part Name Remarks Q'ty New Ver
A1 nsp FRONT UNIT 8U-110161-1 1 *
┣
A
2 - SOURCE UNIT 8U-110161-
2
1
┣
A
3 - VOL UNIT 8U-110161-
3
1
┣
A
4 - PHONO UNIT 8U-110161-
4
1
┣
A
5 - H/P UNIT 8U-110161-
5
1
┣
A
6 - HDAM CONNECT UNI
T
8U-110161-
6
1
┗
A
7 - DOOR SW UNIT 8U-110161-
7
1
B1 nsp XLR OUT UNIT 8U-110162-1 1 *
┣B2 - Q204 UNIT 8U-110162-
2
1
┣B3 - Q203 UNIT 8U-110162-
3
1
┣B4 - Q208 UNIT 8U-110162-
4
1
┣B5 - Q207 UNIT 8U-110162-
5
1
┗B6 - SMPS UNIT 8U-110162-
6
1
C1
9U-210202
(OLD)
HDAM XLR-AMP UNI
T
C4 : 8U-210202-4 FRONT HDMI USB UNIT shall be only for the products with
following serial numbers.
AV8802A U1B : before ABE15xxxx02981
AV8802A N1B : before ABD15161201741
A
V
880
2A K1B :
be
f
o
r
e
AB
C
1
5
xxxx
0066
1
C4 : 8U-210202-4
FRONT HDMI
USB UNIT
Old version
included.
8U-210202-1
(OLD)
1*6
C1
9U-210202V2
(NEW)
HDAM XLR-AMP UNIT
For the products with all serial numbers.
C4 : 8U-210202-
4
FRONT HDMI
USB UNIT
New version
included.
8U-210202-1
(NEW)
1*6
┣C2 - XLR IN
_
TEMOTE IO
_
232C UNI
T
8U-210202-
2
1
┣C3 - CONNECTOR-3 UNI
T
8U-210202-
3
1
┗C4 - FRONT HDMI USB UNIT 8U-210202-
4
1
┗C4 -
FRONT
HDMI
USB
UNIT
This unit from 9U-210202 shall be used only for the product with following serial
number.
AV8802A U1B : before ABE15xxxx02981
AV8802A N1B : before ABD15161201741
AV8802A K1B : before ABC15xxxx00661
This unit from 9U
-
210202V2 is for the products with all serial numbers.
8U-210202-4
(OLD)
8U-210202-4
(NEW)
1*6
D1 nsp AUDIO/VIDEO UNIT 8U-210163-1 1 *
┣D3 - PCB CONNECT-1 8U-210163-
3
1
┣D4 - PCB CONNECT-2 8U-210163-
4
1
┣D8 - PCB CONNECT-4 8U-210163-
8
1
┗D9 - PCB CONNECT-5 8U-210163-
9
1
E1 9U-210164G
PCB
DAC
UNIT
・Replace the PCB DAC UNIT if the issues listed in service bulletin MZ17-072
occur.
・This unit is used in the products with following serial numbers.
AV8802A/U1B : with or after ABE15170603351
AV8802A/N1B : with or after ABD15170701841
AV8802A/K1B : with or after ABC15170900761
8U-210164-1 1 * 8
┗E3 - REAR USB UNIT 8U-210164-
3
1
F 9U-310150G DIGITAL UNIT (U, CX870) AV8802 U 8U-310150G 1 *
F 9U-310150H DIGITAL UNIT (N, CX870) AV8802 N 8U-310150H 1 *
F 9U-310150J DIGITAL UNIT (F, CX870) AV8802 F 8U-310150J 1 *
F
9U-310202G
(OLD)
PWB DIGITAL ASSY (U, CY920)
This unit shall be only for the products with following serial numbers.
A
V8802A U1B : with serial number before ABE15161102911
AV8802A U 8U-310202G 1 * 6
F
9U-310202GV2
(
NEW
)
PWB DIGITAL ASSY (U, CY920)
This unit is for AV8802A U1B with all serial nubers
.
AV8802A U 8U-310202G 1 * 6
F
9U-310202H
(OLD)
PWB DIGITAL ASSY (N, CY920)
This unit shall be only for the products with following serial numbers.
A
V8802A N1B : with serial number before ABD15161101661
AV8802A N 8U-310202H 1 * 6
F
9U-310202HV
2
(
NEW
)
PWB DIGITAL ASSY (N, CY920)
This unit is for AV8802A N1B with all serial nubers
.
AV8802A N 8U-310202H 1 * 6
F
9U-310202K
(OLD)
PWB DIGITAL ASSY (K, CY920)
This unit shall be only for the products with following serial numbers.
A
V8802A K1B : with serial number before ABC15xxxx00661
AV8802A K 8U-310202K 1 * 6
F
9U-310202KV2
(
NEW
)
PWB DIGITAL ASSY (K, CY920)
This unit is for AV8802A K1B with all serial nubers.
AV8802A K 8U-310202K 1 * 6
F 9U-310202J PWB DIGITAL ASSY (F, CY920) AV8802A F 8U-310202J 1 * 3
G1 9U-310201A PCB CX870 CONNECT UNIT(CX870) AV8802 8U-310201-1 1
┗G2 - PCB BT MODULE
(
CX870
)
A
V8802 8U-310202-
2
1
1 nsp MAIN CHASSIS 44131007411AM 1 *
2 nsp BOTTOM PLATE 40531001312AM 1 *
3 nsp TRANS PLATE 44631006910AM 1
4 nsp HDAM BRACKET 44431029900AM 1
5 nsp HDMI STAY (A) 44231010120AM 1 *
6 nsp L BRACKET(A) 44431051800AM 2 *
7 nsp HDAM STAY 44231002900AM 1
8 nsp PLATE RADIATOR AV8801 A368 44641007010AM 1
9 nsp RADIATOR PLATE L 44631007400AM 1
10 40751010010AM FOOT 40751010010AM 4 *
11 43401001100AM FELT PAD 00D4610782015 4 *
12 nsp BRACKET POWER 444310195007D 9
13 nsp SPACER 45151021100AM 1 *
14 nsp BRACKET MOUNT PWB AV8801 A368 44431030300AM 1
! 15 10101023200AS MAIN TRANS(AV8802U Toroidal) U 10101023200AS 1 *
! 15 10101023201AS MAIN TRANS(AV8802N Toroidal) N 10101023201AS 1 *
! 15 10101023202AS MAIN TRANS(AV8802K Toroidal) K 10101023202AS 1 * 3
! 15 10101023203AS MAIN TRANS(AV8802F Toroidal) F 10101023203AS 1 *
16 nsp BACK PANEL U 40631014200AM 1 *
16 nsp BACK PANEL N 40631014201AM 1 *
16 nsp BACK PANEL F 40631014203AM 1 *
17 18301004000AS HD RADIO MODULE(UMH-AVR) U 18301004000AS 1
18 nsp CARD SPACER (L=12) 00D4122814057 5
19 nsp PWB BRACKET (FRONT/CNT) 44431033100AD 1
20 nsp CARD SPACER (L=6) 00D4122814044 1
21 nsp SMPS HOLDER 44431033300AD 1
22 nsp SMPS COVER 44431033200AD 1
23 nsp PWB BRACKET DIGITAL 44431051200AM 1 *
24 nsp Terminal PHONO 48801000200AM 1
★ ns
p
CORD HOLDER
(
L76
)
0RD445004800
3
2
★ ns
p
WASHER 6TW 52135005100AS 2
★ ns
p
WIRE CLAMPER 00D445800400
7
14
25 nsp PC SHEET 45151021600AM 1 *
26 nsp RUBBER FOAM 47101021000AM 2 *
27 nsp PC SHEET(SMPS) 45151021700AM 1 *
28 nsp HEAT SINK(SMPS) 44731010100AD 1
29 nsp RUBBER FOAM 47101021001AM 1 *
