EXPLODED
REF No. Part No. Part Name Remarks Q'ty New Ver
★ 60605016109AS FFC 19P 320mm 1.0m
m
60605016109AS 1 *
★ 60605016200AS FFC 13P 80mm 1.25m
m
U 60605016200AS 1
★ 60605016201AS FFC 33P 130mm 1.25m
m
60605016201AS 1
★ ns
p
3P 340mm PH-PH 61205051800AS 1
★ ns
p
9P 240mm PH-PH 61205052100AS 1
★ ns
p
11P 260mm PH-PH 61205052300AS 1
★ ns
p
12P 260mm PH-PH 61205052400AS 1
★ ns
p
14P 300mm PH-PH 61205052500AS 1
★ ns
p
5P 220mm PH-PH 61205063800AS 1 *
★ ns
p
3P 260mm EH-EH 61205051500AS 1
★ ns
p
3P 300mm PH-PH 61205064000AS 1 *
★ ns
p
10P 290mm PH-PH 61205052200AS 1
★ ns
p
15P 230mm PH-PH 61205052600AS 1
★ ns
p
16P 250mm PH-PH 61205052700AS 1
★ ns
p
8P 380mm PH-PH 61205063900AS 1 *
★ ns
p
6P 250mm EH-EH 61205062900AS 1
30 443510045206M FRONT INNER PANEL BL SR7005 A332 443510045206M 1
31 42251005000AM PLATE JACK BL AV8801 A368 42251005000AM 1
32 471510026002M BUFFER DOOR UD9004 37AK 471510026002M 2
33 41651013000AM WINDOW DOOR 41651013000AM 1 *
34 41651008900AM WINDOW FILTER 41651008900AM 1
35 416510046009M WINDOW CENTER SR7005 A332 416510046009M 1
36 424410019009M RING CENTER BL SR7005 A332 424410019009M 1
37 451510099006M SHEET MEDIUM SR7005 A332 451510099006M 1
38 481510018107M LENS RING SR7005 A332 481510018107M 1
39 481510019100M LENS IR BL SR7005 A332 481510019100M 1
40 40231027904AM FRONT PANEL U 40231027904AM 1 *
40 40231027905AM FRONT PANEL (AL) N 40231027905AM 1 *
40 40231027906AM FRONT PANEL (AL) F 40231027906AM 1 *
41 421410006004M MARANTZ BADGE (AL) FOR M1 MODEL 421410006004M 1
42 40251050100AM ESCUTCHEON (L) 40251050100AM 1 *
43 40251050200AM ESCUTCHEON (R) 40251050200AM 1 *
44 411510121004M BUTTON CURSOR BL SR7005 A332 411510121004M 1
45 411510120001M BUTTON 4KEY BL SR7005 A332 411510120001M 1
46 451510098003M SHEET BUTTON SR7005 A332 451510098003M 2
47 411510122007M BUTTON 11KEY BL SR7005 A332 411510122007M 1
48 411510021005M BUTTON BL 411510021005M 1
49 481510020001M LENS STANDBY SR7005 A332 481510020001M 1
50 nsp SHAFT DOOR SR7005 A332 461310010002M 2
51 415410023103M DOOR BL SR7005 A332 415410023103M 1
52 417510015008M HINGE DOOR BL SR7005 A332 417510015008M 1
53 42251006000AM COVER DOOR INNER 42251006000AM 1 *
54 nsp SPRING DOOR SR7005 A332 473410007008M 1
55 nsp BRACKET DOOR SR7005 A332 444310243005M 1
★ ns
p
P-WASHER WITH ADHESIVE 521550006000
P
1
56 nsp DAMPER DOOR SR7005 A332 474510008003M 1
57 nsp MAGNET DOOR SR7005 A332 457010003008M 1
58 nsp HDMI USB BRACKET 44431030100AM 1
★ 446410050000M PLATE EARTH SR7005 A332 446410050000M 2
59 nsp SHEET 00M316J107010 1
60 nsp FRONT CHASSIS 44131007521AM 1 *
61 nsp PC SHEET 44551014800AS 1
62 nsp RUBBER SHEET (20x10.T6) 47101006701AS 2
★ ns
p
PC SHEET
(
A
)
45151012900AS 4
★ ns
p
PC SHEET
(
B
)
45151013000AS 4
63 nsp FFC HOLDER 44551020600AM 1 *
64 nsp SPACER 43601006000AS 4
65 41201009400AM KNOB BL AV8801 A368 41201009400AM 2
66 424510004006M RING VOLUME BL PM7003 24AJ 424510004006M 2
★ ns
p
POP LABEL
A
V8802 U 54411039300AM 1 *
★ ns
p
POP LABEL
(
N
)
A
V8802 N 54411221500AM 1 *
★ ns
p
POP LABEL
(
F
)
A
V8802 F 54411221700AM 1 *
★ ns
p
POP LABEL
A
V8802A U 54411223000AM 1 * 3
★ ns
p
POP LABEL
(
N
)
A
V8802A N 54411223100AM 1 * 3
★ ns
p
POP LABEL
(
F
)
A
V8802A F 54411223200AM 1 * 3
★ ns
p
POP LABEL
(
K
)
A
V8802A K 54411223200AM 1 * 3
★ ns
p
A
LUMINUM TAPE N 00D414101001
0
45㎜
★ ns
p
SPOTIFY LABEL U, N 54411222000A
D
1
★ ns
p
5P 530mm PH-PH
(
USB
)
61205049400AS 1
★
60605030102AS
FFC 25P(AC+AL)350mm 1.0m
m
This Part is for all the U, F, K products and
A
V8802A N1B : with serial number before ABD15161201741
U, F, K
N (old)
60605030102AS 1 * 6
★
60605030801AS
FFC 25P(SHIELD)350mm 1.0m
m
This Part is for the product with the following serial numbers.
A
V8802A N1B : ABD15161201741 or late
r
N (New) 60605030801AS 1 * 6
★ 60605016108AS FFC 40P 290mm 1.0m
m
60605016108AS 1
★ ns
p
3P 70mm PH-PH 61205051700AS 1
★ ns
p
5P 100mm PH-PH 61205051900AS 1
★ ns
p
7P 300mm PH-PH 61205049703AS 1 *
★ ns
p
UL TUBE
(
16
)
BK 110mm 65401002001AS 1 *
★ ns
p
WIRE CLAMPER 00D445800400
7
2
67 nsp TOP COVER STAY 44231002610AM 2
68 40331006810AM TOP COVER CENTER 40331006810AM 1
69 40331006900AM TOP COVER (L) 40331006900AM 1
70 40331007000AM TOP COVER (R) 40331007000AM 1
71 nsp SHEET DAMPER 00M04AJ056070 1
★ ns
p
GASKET NLCG-030100 44801002602AS 140㎜
★ ns
p
A
LUMINUM TAPE 00D414101000
7
470㎜
★ ns
p
GASKET NLCG-030100 44801002602AS 400㎜
★ ns
p
GASKET NLCG-030100 44801002602AS 120㎜
72 419510012005M MASK TOP LID REAR 419510012005M 1
73 - CX870 MODULE AV8802 18901010100AS 1
┣73 9R1891003400M CX870 MODULE SUB ASSY
(
8802/U CX870
)
A
V8802 U 9R1891003400M 1 *
┣73 9R1891003401M CX870 MODULE SUB ASSY
(
8802/N CX870
)
A
V8802 N 9R1891003401M 1 *
┗73 9R1891003402M CX870 MODULE SUB ASSY
(
8802/F CX870
)
A
V8802 F 9R1891003402M 1 *
74 - CY920 MODULE(CY920) AV8802A 18901006500AS 1 3
┗74 9R1891003100M CY920 MODULE ASSY
(
8802, CY920
)
A
V8802A 9R1891003100M 1 * 3
75-1 943116100580S WIFI ANT WIRE ASSY 300MM -1*5
75-2 943116100570S WIFI ANT WIRE ASSY 450MM -1*5
★ ns
p
UL TUBE
(
16
)K
A
V8802 65401002000AS 1
★ ns
p
5P-6P 160mm PH-PH
A
V8802 61205063200AS 1
★ ns
p
11P XXXmm PH-PH
(
BT
)
A
V8802 61205063300AS 1
★ ns
p
CORD HOLDER
(
L50
)
0RD445004801
6
1
★ ns
p
3P SCN-5P SAN 130mm
A
V8802 61205064300AS 1
★ ns
p
A
LABEL
(
REAR
)
A
V8802
A
54411223400AM 1 * 3
SCREW GROUP
101 nsp SCREW 00M51100306M9 16
102 nsp SCREW 3X10 (+)BH MS CU CLEAR 00M51100310M0 4
103 nsp B.T.SCREW EX600240 00M51260308M0 6
104 nsp SCREW 00M51270308M0 4
105 nsp SCREW 00M51280308M0 60
106 nsp SCREW 00M51280310M0 9
107 nsp SCREW 00M51280312M0 3
64
