1. FRONT PANEL ASSY
Proceeding : TOP COVER → FRONT PANEL ASSY
(1) Remove the nut, the washer and screws.
(2) Cut the wire clampers and remove the connector wires. Remove the screws.
View from the bottom
TOP
bottom
NUT and WASHER
N8502
N2802
N2801
N5901
N102
N9901
CUT
13
