Marantz Icemaker - Technical Specifications; Dimension

Unit : mm
Weight: 10.0kg
22559 45
14 111
125
440
340
56
5050
329 379
2
381
• RMS Power output (20 Hz -20 kHz simultaneous drive of bothchannels) :
60 W x 2 (8
Ω
/ohms load)
80 W x 2 (4
Ω
/ohms load)
• Total harmonic distortion
(20 Hz-20 kHz simultaneous drive of bothchannels, 8
Ω
/ohms load) :
0.02 %
• Output band width (8
Ω
/ohms load, 0.06 %) :
5 Hz - 60 kHz
• Frequency response (CD, 1 W, 8
Ω
/ohms load) :
5 Hz - 100 kHz ± 3 dB
• Dumping factor (8
Ω
/ohms load, 40 Hz
-
20 kHz) :
100
• Input sensitivity/Input impedance
PHONO (MM) :
2.0 mV/47 k
Ω
/kohms
CD, TUNER, NETWORK, RECORDER :
200 mV/20 k
Ω
/kohms
• Maximum allowable PHONO input level (1 kHz) MM :
100 mV
• RIAA deviation (20 Hz
-
20 kHz) :
±
0.5 dB
• S/N (IHF-A, 8
Ω
/ohms load)
PHONO (MM) :
85 dB (5 mV input, 1 W output)
CD, TUNER, NETWORK, RECORDER :
104 dB (2 V input, Rated output)
• Tone Control
BASS (50 Hz) :
±
10 dB
TREBLE (15 kHz) :
±
10 dB
• Power requirement :
(F)AC100V
、
50/60Hz
(N)AC230V, 50/60Hz
(U)AC120V, 60Hz
(K)AC220V
、
50Hz
• Power consumption :
170W
• Power consumption in standby mode :
0.2 W
• Digital input signal format
Format:
Digital audio interface (Linear PCM)
Coaxial input:
0.5 Vp-p / 75 Ω/ohms
Optical input:
More than – 27 dBm
Optical wavelength:
660 nm
TECHNICAL SPECIFICATIONS
DIMENSION
9
