Terminal Function
Pin Port I/O use Name
Port Setting
Note
Act. stby Exit R
1 STROBE I I CE Chip Enable
2 DATA I I DATA From 4094-1
3 CLOCK I I CLK Serial Clock
4 Q1 O O TONE H L PD 10k Tone Control SW (H/L = Tone/Source Direct)
5 Q2 O O P-DIRECT H L PD 10k Power Amp direct in Relay ON (ON:H)
6 Q3 O O CD H L PD 10k CD Input Relay ON (ON:H)
7 Q4 O O LINE H L PD 10k LINE Input Relay ON (ON:H)
8 VSS - - GND - - - GND
9 QS O O QS Open
10 Q'S O O Q'S Open
11 Q8 O O PHONO H L PD 10k PHONO Input Relay ON (ON:H)
12 Q7 O O - - - - -
13 Q6 O O BI H L PD 10k Bi amp SW (H/L = Bi amp/Normal)
14 Q5 O O MM H L PD 10k PHONO MM/MC SW (H/L = MM/MC)
15 OE I I OE Output Enable
16 VDD - - VCC - - - 3.3V
61
