DIGITAL
DIGITAL PCB ASS'
Y
※Parts indicated b
y
"ns
p
"on this table cannot be su
pp
lied.
※The
p
arts listed
b
NOTE:The symbols in the column Remarks indicate the following destinations.
U : North America model N : Europe model K : China model F : Japan model
B : Black model SG : Silver gold model
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
SEMICONDUCTORS GROUP
D0103,0104 20105001230AS 1SS355T 20105001230AS 1
D0301,0302 20105001230AS 1SS355T 20105001230AS 1
D0400-0402 251310004507S CG0603MLC-12LE 251310004507S 1
D0701-0705 20105001230AS 1SS355T 20105001230AS 1
D0800-0802 20105001230AS 1SS355T 20105001230AS 1
Q0101 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q0103 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q0104 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q0105 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q0106 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q0107 00D2730464901 KTC3875S-GR-RTK/P 00D2730464901 1
Q0108 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q0109-0111 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q0112 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q0113 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q0114,0115 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q0116 00D2710312905 KTA1504S-GR-RTK/P 00D2710312905 1
Q0117 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q0118 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q0301 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q0400,0401 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q0403 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q0700 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
Q0701 00D2757001907 FDC608PZ 00D2757001907 1
Q0703 00D2690184907 KRA102S-RTK/P (10K-10K) 00D2690184907 1
Q0704-0706 00D2690192902 KRC102S-RTK/P (10K-10K) 00D2690192902 1
U0101 00D2623639005 M3062LFGPGP 00D2623639005 1
U0102 00D2623082924 BD4730G-TR 00D2623082924 1
U0103 00D2623483905 BR93L66F-W 00D2623483905 1
U0301 00MHC008005KY TC7WHU04FU TRIPLE INVERTER 00MHC008005KY 1
U0302 23681014050AS PCM9211 23681014050AS 1
U0303 00MHC008005KY TC7WHU04FU TRIPLE INVERTER 00MHC008005KY 1
U0304 62201000200AS JSR2124 62201000200AS 1
U0305 14181008150AS NZ2520S(24.576MHz) 14181008150AS 1
U0306 14181007650AS NZ2520SD(22.5792MHz) 14181007650AS 1
U0307,0308 00MHC011805KZ TC74LCX157FT(EL.K) 00MHC011805KZ 1
U0309 00MHC1002088Z CS4398-CZZR/D 00MHC1002088Z 1
U0400 24581003360AS TMS320C6748BZWT3 24581003360AS 1
U0401 - MX25L4006EM1I-12G -1
┗U0401
9R2481025400M SA8005 USB-B ROM SUB ASS
Y
8R2481025400M 1
U0402-0404 23981009450AS ADuM1285CRZ (ISOLATOR) 23981009450AS 1
！ U0700 231810090509S PQ018ENA1ZPH 231810090509S 1
！ U0701 231810071508S PQ012ENB1ZPH 231810071508S 1
U0800 - EPM240T100C5N
-
1
┗U0800
24881024460AS EPM240T100C5N
(
SA14S1
)
00D2623590005 1
U0801 23681011850AS CS2000-CP 23681011850AS 1
U0804,0805 00MHC008005KY TC7WHU04FU TRIPLE INVERTER 00MHC008005KY 1
RESISTOR GROUP
R0101 nsp RM73B--103JT +1608 00D2472009983 1
R0102 nsp RM73B--332JT +1608 00D2472008968 1
R0103 nsp RM73B--103JT +1608 00D2472009983 1
R0104 nsp RM73B--104JT 00D2473013923 1
R0105 nsp RM73B--473JT +1608 00D2472011942 1
R0106 nsp RM73B--103JT +1608 00D2472009983 1
R0107 nsp RM73B--473JT +1608 00D2472011942 1
R0108 nsp RM73B--0R0KT +1608 00D2472018903 1
R0109 nsp RM73B--330JT +1005 00D2473004987 1
R0110 nsp RM73B--104JT 00D2473013923 1
R0111,0112 nsp RM73B--0R0KT +1608 00D2472018903 1
R0113 nsp RM73B--101JT +1608 00D2472005903 1
R0114 nsp RM73B--333JT +1608 00D2472011900 1
R0115-0117 nsp RM73B--560JT 00D2473005944 1
R0118 nsp RM73B--183JT +1608 00D2472010943 1
R0119 nsp RM73B--473JT +1608 00D2472011942 1
R0121 nsp RM73B--101JT +1608 00D2472005903 1
R0122 nsp RM73B--560JT 00D2473005944 1
R0123 nsp RM73B--221JT +1005 00D2473006985 1
R0124 nsp RM73B--560JT 00D2473005944 1
R0125 nsp RM73B--104JT 00D2473013923 1
R0126 nsp RM73B--560JT 00D2473005944 1
R0127 nsp RM73B--104JT 00D2473013923 1
R0128,0129 nsp RM73B--103JT +1005 00D2473010984 1
R0130 nsp RM73B--104JT 00D2473013923 1
R0132,0133 nsp RM73B--103JT +1005 00D2473010984 1
R0134,0135 nsp RM73B--220JT+1005 00D2473004945 1
R0136 nsp RM73B--0R0KT+1005 00D2473001906 1
R0137,0138 nsp RM73B--101JT +1608 00D2472005903 1
R0139 nsp RM73B--103JT +1005 00D2473010984 1
R0140 nsp RM73B--104JT 00D2473013923 1
R0142 nsp RM73B--104JT 00D2473013923 1
R0143-0145 nsp RM73B--473JT+1005 00D2473012940 1
R0146,0147 nsp RM73B--103JT +1005 00D2473010984 1
R0148 nsp RM73B--104JT 00D2473013923 1
R0149,0150 nsp RM73B--473JT +1608 00D2472011942 1
R0151 nsp RM73B--223JT +1608 00D2472010969 1
R0152 nsp RM73B--473JT +1608 00D2472011942 1
R0153 nsp RM73B--103JT +1005 00D2473010984 1
R0154 nsp RM73B--0R0KT+1005 00D2473001906 1
R0155-0159 nsp RM73B--103JT +1608 00D2472009983 1
R0160 nsp RM73B--472JT (1608) +1608 00D2472009909 1
R0161-0163 nsp RM73B--0R0KT+1005 00D2473001906 1
R0164 nsp RM73B--473JT +1608 00D2472011942 1
R0165 nsp RM73B--105JT +1608 00D2472014965 1
R0166 nsp RM73B--102JT +1608 N 00D2472007943 1
R0167 nsp RM73B--473JT +1608 00D2472011942 1
R0168-0170 nsp RM73B--104JT 00D2473013923 1
R0171 nsp RM73B--0R0KT +1608 00D2472018903 1
R0174 nsp RM73B--0R0KT +1608 00D2472018903 1
