EXPLODED
REF No. Part No. Part Name Remarks Q't
y
New
V
e
r
0390C nsp SCREW 00M51100306M9 4
0400C nsp SUPPORT DIGITAL 45231002500AS 1 *
0410C nsp BRACKET DIGITAL PWB 44431034400AM 1 *
0420C nsp SCREW 00M51280308M0 1
0430C nsp SCREW 00M51280308M0 1
0440C nsp SCREW 00M51460306M9 1
0450C nsp SCREW 00M51460306M9 1
0230C nsp SIDE RETAINER L PM7003 24AJ 442310005009M 1
0240C nsp SCREW 00M51280308M0 1
0245C nsp SCREW 00M51290308M0 1
0250C nsp SIDE RETAINER R PM7003 24AJ 442310006002M 1
0260C nsp B.T.SCREW EX600240 00M51260308M0 2
0270C nsp WASHER 00M281K118010 2
0280C nsp BRACKET SA7003 33AK 444310036009M 2
0290C nsp SCREW-B 00M51280308U0 4
0300C nsp CONTACTOR PM7005 48841000301AM 1 *
0310C nsp SCREW 00M51290308M0 1
0320C nsp SCREW 00M51290308M0 2
0340C nsp WIRE CLAMPER 00D4458004007 12
0010R nsp REAR PANEL PM7005 U U 40631014703AM 1 *
0010R nsp REAR PANEL PM7005 N N 40631014700AM 1 *
0010R nsp REAR PANEL PM7005 K K 40631014702AM 1 *
0010R nsp REAR PANEL PM7005 F F 40631014701AM 1 *
0010L nsp CLEAR LABEL(44X12 T0.05) U,K 00M32AK861900 1
0013R nsp USB SPACER 45151013200AM 1
0020R nsp SCREW 00M51270308M0 3
0030R nsp SCREW 00M51270308M0 4
0040R nsp SCREW 00M51460306M9 1
0050R nsp SCREW 00M51270308M0 1
0055R nsp SCREW 00M51460306M9 1
0060R nsp SCREW 00M51290308M0 2
0070R nsp SCREW 00M51270308M0 3
0090R nsp SCREW 00M51280308M0 2
0095R nsp SCREW 00M51460306M9 2
0100R nsp NUT SPEAKER 00M04AJ011110 4 *
0110R nsp SPACER SPEAKER 45101020010AM 1 *
0120R nsp STUD SPEAKER PWB 00M04AJ101110 2 *
0130R nsp SCREW:CD LID EARTH 00M51100304M9 2
0140R nsp SCREW:CD LID EARTH 00M51100304M9 1
0150R nsp SCREW 00M51460306M9 1
0010H nsp MAIN HEATSINK PM7005 44741007700AM 1 *
0020H nsp HEATSINK BRACKET 00M14AJ160010 2
0030H nsp SCREW 00M51280312M0 4
0040H nsp STUD M3 9mm 45241005300AM 6 *
0050H nsp SCREW 00M51480306M9 6
0055H nsp CORD HOLDER (L50) 0RD4450048016 2
0060H nsp SCREW 00M51480315M9 4
0070H nsp SCREW 00M51100308M9 4
0080H nsp SCREW 00M51280308M0 1
0090H nsp BRACKET 00M14AJ160030 1
0100H nsp SCREW 00M51500308M0 2
0500C nsp BUSH SCREW 00M28AK259012 2
! J0001 00D2033996008
A
C INLET
(
2P
)
00D2033996008 1
J0002 nsp TERMINAL 00MYL03010330 1
J0003J0004 64671002401AM SPKT-1 RED 64671002401AM 2
J0005J0006 64671002501AM SPKT-1 WHITE 64671002501AM 2
! T0001 10101023600AM POWER TRANS A400
(
120V
)
U 10101023600AM 1 *
! T0001 10101023300AM POWER TRANS A400
(
230V
)
N,K 10101023300AM 1 *
! T0001 10101023500AM POWER TRANS A400
(
100V
)
F 10101023500AM 1 *
! W0002 nsp VAR-NO CN7.92MMPICH1PIN:BR.2PIN:BL10CM 120109160060 1
W0003 nsp VAR-VAR 7.92MMPICH 1PIN:BR.2PIN:BR22CM 120108950000 1
W0004 nsp 12P L=190 PHR-PHR UL1061 AWG28 61205062300AM 1 *
W0005 nsp 3P L=130 EHR-EHR UL1430 AWG26 61205062400AM 1 *
W0006 nsp 4P L=380 EHR-EHR UL1430 AWG26 61205061800AM 1 *
W0007 nsp 8P L=300 PHR-PHR UL1061 AWG28 61205062100AM 1 *
W0008 nsp VHR-VHR(NTYPE)3.96MM 4PIN 19CM 612050091008M 1
W0010 nsp 3P L=330 EHR-EHR UL1430 AWG26 61205061900AM 1 *
W0011 nsp 14P L=210 PHR-PHR UL1061 AWG28 61205062200AM 1 *
W0012 nsp 10P L=60 PHR-PHR UL1061 AWG28 61205062500AM 1 *
L0001 nsp FERRITE CORE GRFC-4 11701001502AS 1
! KT701 2170500010040 2SA1186/2SC2837 RANK Y
P
2170500010040 1
!
┣Q7011
ns
p
2SC2837 RANK Y
P
2130500030080 1
!
┗Q7013
ns
p
2SA1186 RANK Y
P
2110500030020 1
! KT702 2170500010040 2SA1186/2SC2837 RANK Y
P
2170500010040 1
!
┣Q7012
ns
p
2SC2837 RANK Y
P
2130500030080 1
!
┗Q7014
ns
p
2SA1186 RANK Y
P
2110500030020 1
12
