Marantz M-CR510 - Specifications; Audio section specifications

98
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
Appendix
2 Audio section
•Audio amplifier
Rated output: 2-channel driving
50 W + 50 W (6 Ω/ohms, 1 kHz, THD+N 0.7 %)
Dynamic power: 60 W + 60 W (6 Ω/ohms, 1 kHz, THD+N 10 %)
Output terminals: Speaker 6 – 8 Ω/ohms
Suited for headphones/stereo headphones
Input sensitivity/impedance: Analog In : 200 mV/22 kΩ/kohms
THD+N (1 kHz, 5 W, 6 Ω/ohms): Analog In : 0.1 %
S/N ratio (10 W, 6 Ω/ohms, IHF-A): Analog In : 86 dB
Tone control: Dynamic Bass Boost : 100 Hz +8 dB
BASS : 100 Hz ± 10 dB
TREBLE : 10 kHz ± 10 dB
Frequency response: Analog In : 5 Hz – 22 kHz (± 3dB)
Specifications
